LT3980EDE Integrated Circuit Chip 2.4MHz Step-Down Switching Regulator With 85µA Quiescent Current
Product Description
LT3980EDE is an adjustable frequency (100kHz to 2.4MHz) monolithic buck switching regulator that accepts input voltages up to 58V (80V transient). A high efficiency 200mΩ switch is included on the die along with a boost Schottky diode and the necessary oscillator, control, and logic circuitry.
Specifications
| Function |
Step-Down |
| Output Configuration |
Positive |
| Topology |
Buck |
| Output Type |
Adjustable |
| Number of Outputs |
1 |
| Voltage - Input (Min) |
3.6V |
| Voltage - Input (Max) |
58V |
| Voltage - Output (Min/Fixed) |
0.79V |
| Voltage - Output (Max) |
57.42V |
| Current - Output |
2A |
| Frequency - Switching |
225kHz ~ 2.25MHz |
| Synchronous Rectifier |
No |
| Operating Temperature |
-40°C ~ 125°C (TJ) |
Features
- Wide Input Range: Operation from 3.6V to 58V
- Overvoltage Lockout Protects Circuits Through 80V Transients
- 2A Maximum Output Current
- Low Ripple (<15mVP-P) Burst Mode® Operation: IQ = 85µA at 12VIN to 3.3VOUT
- Adjustable Switching Frequency: 100kHz to 2.4MHz
- Low Shutdown Current: IQ < 1µA
- Catch Diode Current Sense Protects Circuit Through Short-Circuit and Input Overvoltage
- Synchronizable Between 250kHz to 2MHz
- Power Good Flag
- Saturating Switch Design: 200mΩ On-Resistance
- Thermal Protection
- Soft-Start Capability
- Small 16-Pin Thermally Enhanced MSOP and 3mm × 4mm DFN Packages
Applications
Automotive Battery Regulation, Distributed Supply Regulation, Industrial Supplies, Wall Transformer Regulation
