VND5E012MYTR Integrated Circuit Chip 52A Double Channel High-Side Driver PowerSSO-36

Large Image : VND5E012MYTR Integrated Circuit Chip 52A Double Channel High-Side Driver PowerSSO-36

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	VND5E012MYTR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	PowerSSO-36
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

VND5E012MYTR Integrated Circuit Chip 52A Double Channel High-Side Driver PowerSSO-36

Description

Part Number:	VND5E012MYTR	Number Of Drivers:	2 Driver
Type:	High-Side	Output Current:	74 A
Operating Supply Current:	3.5 MA	Operating Temperature:	-40°C ~ 150°C (TJ)
Highlight:	Integrated Circuit Chip 52A high-side driver , PowerSSO-36 IC chip , Double channel driver IC

VND5E012MYTR Integrated Circuit Chip 52A Double Channel High-Side Driver PowerSSO-36

Product Description

VND5E012MYTR is Double channel high-side driver with analog current sense for automotive applications. VND5E012MYTR is designed to drive 12 V automotive grounded loads delivering protection, diagnostics and easy 3 V and 5 V CMOS compatible interface with any microcontroller.

Specifications

Switch Type	General Purpose
Number of Outputs	2
Ratio - Input:Output	1:1
Output Configuration	High Side
Output Type	N-Channel
Interface	On/Off
Voltage - Load	4.5V ~ 28V
Voltage - Supply (Vcc/Vdd)	Not Required
Current - Output (Max)	52A
Rds On (Typ)	11mOhm
Input Type	Non-Inverting
Features	Auto Restart
Fault Protection	Current Limiting (Fixed), Over Temperature, Over Voltage
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PowerSSO-36 EPD
Package / Case	36-PowerBFSOP (0.295", 7.50mm Width)

Features

General

Inrush current active management by power limitation
Very low standby current
3.0V CMOS compatible inputs
Optimized electromagnetic emissions
Very low electromagnetic susceptibility
In compliance with the 2002/95/EC european directive
Very low current sense leakage

Diagnostic functions

Proportional load current sense
High current sense precision for wide current range
Current sense disable
Overload and short to ground (power limitation) indication
Thermal shutdown indication

Protections

Undervoltage shutdown
Overvoltage clamp
Load current limitation
Self limiting of fast thermal transients
Protection against loss of ground and loss of VCC
Overtemperature shutdown with auto restart (thermal shutdown)
Reverse battery protection with self switch on of the Power MOSFET
Electrostatic discharge protection

Applications

All types of resistive, inductive and capacitive loads
Suitable as LED driver
