DS1302Z Integrated Circuit Chip Trickle-Charge Timekeeping Chip 31B Serial Address RTCs
Product Description
DS1302Z Trickle-charge timekeeping chip contains a real-time clock/calendar and 31 bytes of static RAM. DS1302Z communicates with a microprocessor via a simple serial interface. The real-time clock/calendar provides seconds, minutes, hours, day, date, month, and year information. The end of the month date is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in either the 24-hour or 12-hour format with an AM/PM indicator.
Specification
| Switch Type |
USB Switch |
| Number of Outputs |
1 |
| Ratio - Input:Output |
1:1 |
| Output Configuration |
High Side |
| Output Type |
N-Channel |
| Interface |
On/Off |
| Voltage - Load |
4.5V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) |
Not Required |
| Current - Output (Max) |
2A |
| Rds On (Typ) |
72mOhm |
| Input Type |
Non-Inverting |
| Features |
Output Discharge |
| Fault Protection |
Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO |
| Operating Temperature |
-40°C ~ 85°C (TA) |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
8-VSSOP |
| Package / Case |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
Features
- Completely Manages All Timekeeping Functions
- Real-Time Clock Counts Seconds, Minutes, Hours, Date of the Month, Month, Day of the Week, and Year with Leap-Year Compensation Valid Up to 2100
- 31 x 8 Battery-Backed General-Purpose RAM
- Simple Serial Port Interfaces to Most Microcontrollers
- Simple 3-Wire Interface
- TTL-Compatible (VCC = 5V)
- Single-Byte or Multiple-Byte (Burst Mode) Data Transfer for Read or Write of Clock or RAM Data
- Low Power Operation Extends Battery Backup Run Time
- 2.0V to 5.5V Full Operation
- Uses Less Than 300nA at 2.0V
- 8-Pin DIP and 8-Pin SO Minimizes Required Space
- Optional Industrial Temperature Range: -40°C to +85°C Supports Operation in a Wide Range of Applications
