L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers

L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers
L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers

Large Image :  L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: L6205D013TR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-20
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, Western Union
Contact Now

L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers

Description
Part Number: L6205D013TR Type: Full Bridge
Output Current: 2.8 A Operating Supply Current: 10 MA
Operating Temperature: -25°C ~ 125°C (TJ) Voltage - Supply: 8V ~ 52V
Highlight:

DMOS dual full bridge driver IC

,

SOIC20 motor driver chip

,

L6205D013TR integrated circuit

L6205D013TR Integrated Circuit Chip DMOS Dual Full Bridge Drivers SOIC20 Motor Drivers
Product Description

L6205D013TR is a DMOS Dual Full Bridge designed for motor control applications, realized in MultiPower-BCD technology, which combines isolated DMOS Power Transistors with CMOS and bipolar circuits on the same chip. Available in PowerSO20 and SO20(16+2+2) packages, the L6205D013TR features a non-dissipative protection of the high side PowerMOSFETs and thermal shutdown.

Specifications
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Parallel
Technology BiCDMOS
Applications General Purpose
Current - Output 2.8A
Voltage - Supply 8V ~ 52V
Voltage - Load 8V ~ 52V
Operating Temperature -25°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295", 7.50mm Width)
Supplier Device Package 20-SO
Features
  • Integrated Fast Free-Wheeling Diode
  • Undervoltage Lockout
  • Cross-Conduction Protection
  • Parallel Operation
  • Operating Supply Voltage 8 to 52V
  • RDS(ON) 0.3 typ. at 5.6A Output Peak Current (2.8A DC)
  • Non-Thermally Controlled Overcurrent Protection
  • Thermal Shutdown
  • Operating Frequency up to 100kHz
Typical Applications
  • Bipolar Stepper Motors
  • Dual or Quad DC Motors
