UCC37322DGNR Integrated Circuit Chip Single 9A High-Speed Low-Side Mosfet Driver With Enable

UCC37322DGNR Integrated Circuit Chip Single 9A High-Speed Low-Side Mosfet Driver With Enable

Product Description Of UCC37322DGNR
UCC37322DGNR is high-speed drivers deliver 9 A of peak drive current in an industry standard pinout. These drivers can drive the largest of MOSFETs for systems requiring extreme Miller current due to high dV/dt transitions.

Specifications Of UCC37322DGNR

Features Of UCC37322DGNR
Industry-Standard Pin-Out With Addition of Enable Function
High-Peak Current Drive Capability of ±9 A at theMiller plateau region Using TrueDrive
Efficient Constant Current Sourcing Using a Unique BiPolar and CMOS Output Stage
TTL/CMOS Compatible Inputs Independent of Supply Voltage
20-ns Typical Rise and Fall Times With 10-nF Load
Typical Propagation Delay Times of 25 ns With Input Falling and 35 ns With Input Rising
4-V to 15-V Supply Voltage
Available in Thermally Enhanced MSOP PowerPAD™ Package With 4.7°C/W θjc
Rated From –40°C to +105°C
Pb-Free Finish (CU NIPDAU) on 8-pin SOIC and PDIP Packages

Applications Of UCC37322DGNR
Switch Mode Power Supplies
DC-DC Converters
Motor Controllers
Class-D Switching Amplifiers
Line Drivers
Pulse Transformer Drivers

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
