DRV8323SRTAR Integrated Circuit Chip Three-Phase Smart Gate Driver With Current Shunt Amplifiers

DRV8323SRTAR Integrated Circuit Chip Three-Phase Smart Gate Driver With Current Shunt Amplifiers

Product Description Of DRV8323SRTAR
DRV8323SRTAR is an integrated gate driver for three-phase applications. The devices provide three half-bridge gate drivers, each capable of driving high-side and low-side N-channel power MOSFETs. The DRV8323SRTAR generates the correct gate drive voltages using an integrated charge pump for the high-side MOSFETs and a linear regulator for the low-side MOSFETs.

Specifications Of DRV8323SRTAR

Features Of DRV8323SRTAR
• Triple Half-Bridge Gate Driver
– Drives 3 High-Side and 3 Low-Side N-Channel MOSFETs (NMOS)
• Smart Gate Drive Architecture
– Adjustable Slew Rate Control
– 10-mA to 1-A Peak Source Current
– 20-mA to 2-A Peak Sink Current
• Integrated Gate Driver Power Supplies
– Supports 100% PWM Duty Cycle
– High-Side Charge Pump
– Low-Side Linear Regulator
• 6 to 60-V Operating Voltage Range
• Optional Integrated Buck Regulator
– LMR16006X SIMPLE SWITCHER®
– 4 to 60-V Operating Voltage Range
– 0.8 to 60-V, 600-mA Output Capability
• Optional Integrated Triple Current Sense Amplifiers (CSAs)
– Adjustable Gain (5, 10, 20, 40 V/V)
– Bidirectional or Unidirectional Support
• SPI and Hardware Interface Available
• 6x, 3x, 1x, and Independent PWM Modes
• Supports 1.8-V, 3.3-V, and 5-V Logic Inputs
• Low-Power Sleep Mode (12 µA)
• Linear Voltage Regulator, 3.3 V, 30 mA
• Compact QFN Packages and Footprints
• Efficient System Design With Power Blocks
• Integrated Protection Features
– VM Undervoltage Lockout (UVLO)
– Charge Pump Undervoltage (CPUV)
– MOSFET Overcurrent Protection (OCP)
– Gate Driver Fault (GDF)
– Thermal Warning and Shutdown (OTW/OTSD)
– Fault Condition Indicator (nFAULT)

Applications Of DRV8323SRTAR
Brushless-DC (BLDC) Motor Modules and PMSM
Fans, Pumps, and Servo Drives
E-Bikes, E-Scooters, and E-Mobility
Cordless Garden and Power Tools, Lawnmowers
Cordless Vacuum Cleaners
Drones, Robotics, and RC Toys
Industrial and Logistics Robots
