BTS6142D Integrated Circuit Chip 1-Channel 12mΩ Smart High-Side Power Switch with 7 A Output Current

Description
Part Number: BTS6142D Number Of Outputs:: 1 Output
Output Current:: 7 A Current Limit:: 50 A
On Resistance - Max:: 12 MOhms On Time - Max:: 600 Us
Highlight:

MAXM17712EVKIT Embedded Solutions

,

MAXM17712EVKIT

BTS6142D Integrated Circuit Chip 1-Channel 12mΩ Smart High-Side Power Switch
Product Description
The BTS6142D is a one-channel high-side power switch in PG-TO252-5-11 package featuring embedded protective functions including ReverSave™ technology. The power transistor is constructed using an N-channel vertical power MOSFET with charge pump, based on Smart SIPMOS chip-on-chip technology.
Specifications
Number of Outputs 1
Ratio - Input:Output 1:1
Output Configuration High Side
Output Type N-Channel
Interface On/Off
Voltage - Load 5.5V ~ 38V
Voltage - Supply (Vcc/Vdd) Not Required
Current - Output (Max) 33A
Rds On (Typ) 10mOhm
Input Type Non-Inverting
Features Auto Restart
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature -40°C ~ 150°C (TJ)
Basic Features
  • Very low standby current
  • Current controlled input pin
  • Improved electromagnetic compatibility (EMC)
  • Fast demagnetization of inductive loads
  • Stable behavior at under-voltage
  • Green Product (RoHS compliant)
  • AEC qualified
Protective Functions
  • ReverSave™ - channel switches on in case of reverse polarity
  • Reverse battery protection without external components
  • Short circuit protection with latch
  • Over-load protection
  • Multi-step current limitation
  • Thermal shutdown with restart
  • Over-voltage protection (including load dump)
  • Loss of ground protection
  • Loss of Vbb protection (with external diode for charged inductive loads)
  • Electrostatic discharge protection (ESD)
Diagnostic Functions
  • Proportional load current sense (with defined fault signal in case of overload operation, over temperature shutdown and/or short circuit shutdown)
  • Open load detection in ON-state by load current sense
Applications
  • µC compatible high-side power switch with diagnostic feedback for 12V grounded loads
  • All types of resistive, inductive and capacitive loads
  • Most suitable for loads with high inrush currents, such as lamps
  • Replaces electromechanical relays, fuses and discrete circuits
