ADG621BRMZ Integrated Circuit Chip Dual SPST Switch IC with 10-lead MSOP Package 2.7V to 5.5V Single Supply and ±2.7V to ±5.5V Dual Supply

Large Image : ADG621BRMZ Integrated Circuit Chip Dual SPST Switch IC with 10-lead MSOP Package 2.7V to 5.5V Single Supply and ±2.7V to ±5.5V Dual Supply

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	ADG621BRMZ

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	MSOP-10
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

ADG621BRMZ Integrated Circuit Chip Dual SPST Switch IC with 10-lead MSOP Package 2.7V to 5.5V Single Supply and ±2.7V to ±5.5V Dual Supply

Description

Part Number:	ADG621BRMZ	Number Of Channels:	2 Channel
Configuration:	2 X SPST	On Resistance - Max:	5.5 Ohms
Pd - Power Dissipation:	10 UW	Supply Current - Max:	1 UA
Highlight:	10-lead MSOP Package Integrated Circuit Chip , 2.7V to 5.5V Single Supply Dual SPST Switch IC , ±2.7V to ±5.5V Dual Supply Analog Switches

ADG621BRMZ Integrated Circuit Chip Dual SPST Switch IC MSOP10 Analog Switches

Product Description

The ADG621BRMZ is a monolithic CMOS single-pole, single-throw (SPST) switch that conducts equally well in both directions when on. This IC features:

Low on resistance of 4 Ω (matched to within 0.25 Ω between channels)
Low power dissipation with high switching speeds

Specifications

Parameter	Value
Switch Circuit	SPST - NO
Multiplexer/Demultiplexer Circuit	1:1
Number of Circuits	2
On-State Resistance (Max)	5.5Ω
Channel-to-Channel Matching (ΔRon)	250mΩ
Voltage - Supply, Single (V+)	2.7V ~ 5.5V
Voltage - Supply, Dual (V±)	±2.7V ~ 5.5V
Switch Time (Ton, Toff) (Max)	120ns, 70ns
-3db Bandwidth	230MHz
Charge Injection	110pC
Channel Capacitance (CS(off), CD(off))	20pF, 20pF
Current - Leakage (IS(off)) (Max)	250pA
Crosstalk	-90dB @ 1MHz
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package	10-MSOP

Key Features

6.6 Ω (maximum) on resistance
0.9 Ω (typical) on resistance flatness
2.7 V to 5.5 V single supply
±2.7 V to ±5.5 V dual supply
Rail-to-rail operation
10-lead MSOP package
Typical power consumption: <0.01 µW
TTL-/CMOS-compatible inputs

Applications

Automatic test equipment
Power routing
Communication systems
Data acquisition systems
Sample-and-hold systems
Relay replacements
Battery-powered systems
