LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature

LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature
LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature

Large Image :  LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LTC3803HS6-5
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSOT-23-6
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

LTC3803HS6-5 Integrated Circuit Chip Flyback Controller with 200kHz Frequency 4V to 8.1V Supply Voltage and -40°C to 150°C Operating Temperature

Description
Part Number: LTC3803HS6-5 Topology: Flyback
Switching Frequency: 200 KHz Operating Supply Current: 240 UA
Voltage - Supply (Vcc/Vdd): 4V ~ 8.1V Operating Temperature: -40°C ~ 150°C (TJ)
Highlight:

200kHz Frequency Flyback Controller

,

4V to 8.1V Supply Voltage Integrated Circuit Chip

,

-40°C to 150°C Operating Temperature Flyback Controller

LTC3803HS6-5 Integrated Circuit Chip 200kHz Frequency Current Mode Flyback Controller
Product Description
The LTC3803HS6-5 is a constant frequency current mode flyback controller optimized for driving N-channel MOSFETs in high input voltage applications. It provides ±1.5% output voltage accuracy and consumes only 240μA of quiescent current. Ground-referenced current sensing allows LTC3803-based converters to accept input.
Specifications
Function Step-Up/Step-Down
Output Configuration Positive, Isolation Capable
Topology Flyback
Number of Outputs 1
Output Phases 1
Voltage - Supply (Vcc/Vdd) 4V ~ 8.1V
Frequency - Switching 200kHz
Duty Cycle (Max) 80%
Synchronous Rectifier No
Clock Sync No
Control Features Current Limit, Enable
Operating Temperature -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Supplier Device Package TSOT-23-6
Key Features
  • VIN and VOUT Limited Only by External Components
  • Adjustable Slope Compensation
  • Internal Soft-Start
  • Constant Frequency 200kHz Operation
  • ±1.5% Reference Accuracy
  • Current Mode Operation for Excellent Line and Load Transient Response
  • No Minimum Load Requirement
  • Low Quiescent Current: 240μA
Applications
  • Telecom Power Supplies
  • 42V and 12V Automotive Power Supplies
  • Auxiliary/Housekeeping Power Supplies
  • Power Over Ethernet
