MAX96752FGTN/V Integrated Circuit Chip GMSL2 Deserializer with 6 Gb/s Data Rate Dual LVDS Output in Compact 8mm x 8mm TQFN Package

Large Image : MAX96752FGTN/V Integrated Circuit Chip GMSL2 Deserializer with 6 Gb/s Data Rate Dual LVDS Output in Compact 8mm x 8mm TQFN Package

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	MAX96752FGTN/V

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TQFN-56
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

MAX96752FGTN/V Integrated Circuit Chip GMSL2 Deserializer with 6 Gb/s Data Rate Dual LVDS Output in Compact 8mm x 8mm TQFN Package

Description

Part Number:	MAX96752FGTN/V	Data Rate::	6 Gb/s
Input Type::	Serial	Number Of Inputs::	2 Input
Output Type::	LVDC	Number Of Outputs::	2 Output
Highlight:	6 Gb/s Data Rate Integrated Circuit Chip , Compact 8mm x 8mm TQFN Package GMSL2 Deserializer , Dual LVDS Output MAX96752FGTN/V

MAX96752FGTN/V Integrated Circuit Chip GMSL2 Deserializer With Dual LVDS Output

Product Description

MAX96752FGTN/V deserializers convert a single- or dual-link GMSL™ serial input to single or dual OLDI. They also send and receive side channel and peripheral control data, enabling full-duplex, single-wire transmission of video and bidirectional data.

Specifications

Data Rate:	6 Gb/s
Input Type:	Serial
Output Type:	LVDC
Number of Inputs:	2 Input
Number of Outputs:	2 Output
Supply Voltage - Max:	1.9 V
Supply Voltage - Min:	1.7 V
Minimum Operating Temperature:	-40°C
Maximum Operating Temperature:	+105°C
Moisture Sensitive:	Yes
Operating Supply Current:	125 mA
Pd - Power Dissipation:	2.2 W

Features

1 x 4, 2 x 4, or 1 x 8 OLDI Output Lane Configurations
3Gbps or 6Gbps Forward Link Rates for System and Power Flexibility
Full-Duplex Capability Over a Single Wire
Supports Up to 300MHz PCLK
Supports Video Replication and Dual-View Splitting for Driving Two Displays
Uses Low-Cost 50Ω Coax or 100Ω STP Cables
Forward and Reverse I2S or 7.1 TDM Audio
Optional Internal VDD Regulator
ASIL-Relevant Functional Safety Features
- ASIL-B Compliant
- 16-Bit CRC Protection of Control Channel Data (I2C, UART, SPI, GPIO, Audio)
- Retransmission of All Control Channel Data (I2C, UART, SPI, GPIO, Audio) Upon Error Detection
- Optional 32-Bit Video Line Cyclic Redundancy Check (CRC)
- Selectable Interrupts for Fault Detection
- Video Watermark Detection
Performance Tools Ensure High Link Margin
- Continuous Adaptive Equalization on GMSL links
- Forward and Reverse Channel Pseudorandom Binary Sequence (PRBS) Generator and Checker for BER Testing of Serial I/O Links
- Eye-Opening Monitor for Continuous Link Margin Diagnosis
Concurrent Control Channel for Device Configuration and Communicating with Remote Peripherals
- I2C, UART, Pass-Through I2C/UART, SPI, and Tunneled or Register-Programmable GPIO
- Settable Priority Levels
- Eight Hardware Programmable Device Addresses
- Up to 14 Programmable General Purpose Input/Output (GPIO)
- Sleep Mode with Register State Retention
Compact 8mm x 8mm TQFN Package with Exposed Pad

Applications

Cluster and Heads-Up Displays
Central Information Displays
Rear-Seat Infotainment Displays
