ADG5236BRUZ Integrated Circuit IC Chip with 2 Channel Dual SPDT Switches 200 Ohms On Resistance and 9V to 40V Supply Voltage

Description

Part Number:	ADG5236BRUZ	Number Of Channels::	2 Channel
Configuration::	2 X SPDT	On Resistance - Max::	200 Ohms
Supply Voltage - Min::	9 V	Supply Voltage - Max::	40 V
Highlight:	2 Channel IC Chip , 200 Ohms On Resistance Integrated Circuit Chip , 9V to 40V Supply Voltage IC Chip

ADG5236BRUZ Integrated Circuit Chip High Voltage Latch-Up Proof Dual SPDT Switches

Product Description

The ADG5236BRUZ is a monolithic CMOS device featuring two independently selectable single-pole/double throw (SPDT) switches. The LFCSP package includes an EN input for device enable/disable functionality. When disabled, all channels switch off. Each switch conducts bidirectionally when active and handles input signals across the full supply range. The switches feature break-before-make switching action, making them ideal for multiplexer applications.

Specifications

Parameter	Value
Switch Circuit	SPDT
Multiplexer/Demultiplexer Circuit	2:1
Number of Circuits	2
On-State Resistance (Max)	160Ω
Channel-to-Channel Matching (ΔRon)	1.3Ω
Voltage - Supply, Single (V+)	9V - 40V
Voltage - Supply, Dual (V±)	±9V - ±22V
Switch Time (Ton, Toff) (Max)	190ns, 180ns
-3db Bandwidth	266MHz
Charge Injection	-0.6pC
Channel Capacitance (CS(off), CD(off))	2.5pF, 12pF
Current - Leakage (IS(off)) (Max)	100pA
Crosstalk	-85dB @ 1MHz
Operating Temperature	-40°C - 125°C (TA)

Key Features

Latch-up immune under all operating conditions
2.5 pF off source capacitance
12 pF off drain capacitance
−0.6 pC charge injection
Low leakage: 0.4 nA maximum at 85°C
±9 V to ±22 V dual-supply operation
9 V to 40 V single-supply operation
48 V supply maximum ratings
Fully specified at ±15 V, ±20 V, +12 V, and +36 V
VSS to VDD analog signal range

Product Highlights

1. Trench Isolation Guards Against Latch-Up A dielectric trench separates the P and N channel transistors, preventing latch-up even under severe overvoltage conditions.

2. Ultralow Capacitance and <1 pC Charge Injection Exceptional signal integrity with minimal interference.

3. Dual-Supply Operation Supports bipolar analog signals with dual supplies up to ±22 V.

4. Single-Supply Operation Handles unipolar analog signals with single rail power supply up to 40 V.

5. 3 V Logic-Compatible Digital Inputs VINH = 2.0 V, VINL = 0.8 V.

6. No VL Logic Power Supply Required Simplified power requirements for easier system integration.

Applications

High voltage signal routing Automatic test equipment Analog front-end circuits Precision data acquisition Industrial instrumentation Amplifier gain select Relay replacement
