TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage

TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage
TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage

Large Image :  TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TNY284KG
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 12-BESOP
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

TNY284KG Integrated Circuit Chip Power Supply Controller with 725V Rated MOSFET 11W Output Power and 85V to 265V Output Voltage

Description
Part Number: TNY284KG Output Voltage:: 85 V To 265 V
Output Power:: 11 W Input / Supply Voltage - Min:: 85 VAC
Input / Supply Voltage - Max:: 265 VAC Duty Cycle - Max:: 67 %
Highlight:

725V Rated MOSFET Integrated Circuit Chip

,

11W Output Power Power Supply Controller

,

85V to 265V Output Voltage TinySwitch-4 Series

TNY284KG Integrated Circuit Chip Energy-Efficient Off-Line Switcher With Line Compensated Overload Power
Product Description
TNY284KG is an energy-efficient offline switching power supply controller belonging to the TinySwitch-4 series. Designed specifically for offline power supply applications requiring high efficiency and low power consumption, this controller incorporates line compensation and overload power capability.
Specifications
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 725V
Topology Flyback
Duty Cycle 67%
Frequency - Switching 124kHz ~ 140kHz
Power (Watts) 6 W
Fault Protection Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit
Control Features EN
Operating Temperature -40°C ~ 150°C (TJ)
Product Highlights
Lowest System Cost with Enhanced Flexibility
  • 725 V rated MOSFET
  • Increases BV de-rating margin
  • Line compensated overload power - no additional components
  • Dramatically reduces max overload variation over universal input voltage range
  • ±5% turn on UV threshold: line voltage sense with single external resistor
  • Simple ON/OFF control, no loop compensation needed
  • Selectable current limit through BP/M capacitor value
  • Higher current limit extends peak power or, in open frame applications, maximum continuous power
  • Lower current limit improves efficiency in enclosed adapters/chargers
  • Allows optimum TinySwitch™-4 choice by swapping devices with no other circuit redesign
  • Tight I2f parameter tolerance reduces system cost
  • Maximizes MOSFET and magnetics utilization
  • ON-time extension - extends low-line regulation range/hold-up time to reduce input bulk capacitance
  • Self-biased: no bias winding or bias components
  • Frequency jittering reduces EMI filter costs
  • Pin-out simplifies heat sinking to the PCB
  • SOURCE pins are electrically quiet for low EMI
Enhanced Safety and Reliability Features
  • Accurate hysteretic thermal shutdown protection with automatic recovery eliminates need for manual reset
  • Auto-restart delivers <3% of maximum power in short-circuit and open loop fault conditions
  • Output overvoltage shutdown with optional Zener
  • Fast AC reset with optional UV external resistor
  • Very low component count enhances reliability and enables single-sided printed circuit board layout
  • High bandwidth provides fast turn-on with no overshoot and excellent transient load response
  • Extended creepage between DRAIN and all other pins improves field reliability
EcoSmart™- Extremely Energy Efficient
  • Easily meets all global energy efficiency regulations
  • No-load <30 mW with bias winding, <150 mW at 265 VAC without bias winding
  • ON/OFF control provides constant efficiency down to very light loads - ideal for mandatory CEC regulations and EuP standby requirements
Applications
  • PC Standby and other auxiliary supplies
  • DVD/PVR and other low power set top decoders
  • Supplies for appliances, industrial systems, metering, etc
  • Chargers/adapters for cell/cordless phones, PDAs, digital cameras, MP3/portable audio, shavers, etc.
