TJA1049TK Integrated Circuit Chip 5Mbps High Speed CAN Transceiver with 300 mV Receiver Hysteresis and 4.75V ~ 5.25V Supply Voltage

Large Image : TJA1049TK Integrated Circuit Chip 5Mbps High Speed CAN Transceiver with 300 mV Receiver Hysteresis and 4.75V ~ 5.25V Supply Voltage

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	TJA1049TK

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	HVSON-8
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

TJA1049TK Integrated Circuit Chip 5Mbps High Speed CAN Transceiver with 300 mV Receiver Hysteresis and 4.75V ~ 5.25V Supply Voltage

Description

Part Number:	TJA1049TK	Protocol:	CANbus
Receiver Hysteresis:	300 MV	Data Rate:	5Mbps
Voltage - Supply:	4.75V ~ 5.25V	Operating Temperature:	-40°C ~ 150°C
Highlight:	5Mbps High Speed CAN Transceiver , 300 mV Receiver Hysteresis CAN Interface IC , 4.75V ~ 5.25V Supply Voltage Integrated Circuit Chip

TJA1049TK Integrated Circuit Chip 5Mbps High Speed CAN Transceiver HVSON8 CAN Interface IC

Product Description

The TJA1049TK is a high-speed CAN transceiver with standby mode, providing an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. Designed for high-speed CAN applications in the automotive industry, it supplies differential transmit and receive capability to a microcontroller with CAN protocol controller.

Specifications

Series	TJA1049
Type	High Speed CAN Transceiver
Mounting Style	SMD/SMT
Package / Case	HVSON-8
Number of Drivers	1 Driver
Number of Receivers	1 Receiver
Supply Voltage - Min	4.75 V
Supply Voltage - Max	5.25 V
Minimum Operating Temperature	-40 ℃
Maximum Operating Temperature	+150 ℃
Operating Supply Current	77.5 mA
ESD Protection	8 kV
Isolation Type	Non-Isolated
Operating Supply Voltage	4.75 V to 5.25 V
Propagation Delay Time	90 ns

Key Features

Timing guaranteed for data rates up to 5 Mbit/s in the CAN FD fast phase
Suitable for 12 V and 24 V systems
Low electromagnetic emission (EME) and high ElectroMagnetic Immunity (EMI)
VIO input allows for direct interfacing with 3 V to 5 V microcontrollers
SPLIT voltage output for stabilizing recessive bus level
Leadless HVSON8 package (3.0 mm * 3.0 mm) with improved Automated Optical Inspection (AOI) capability

Low-power Management

Very low-current Standby mode with host and bus wake-up capability
Functional behavior predictable under all supply conditions
Transceiver disengages from the bus when not powered up (zero load)

Protection Features

High ESD handling capability on the bus pins
Bus pins protected against transients in automotive environments
Transmit Data (TXD) dominant time-out function
Bus-dominant time-out function in Standby mode
Undervoltage detection on pins VCC and VIO
Thermally protected
