DS64BR111SQ Integrated Circuit Chip 6.4Gbps Dual Channel Repeater For Serial Links WQFN24
Product Description
The DS64BR111SQ is an extremely low power, high performance dual-channel repeater for serial links with data rates up to 6.4 Gbps. The DS64BR111 pinout is configured as one bidirectional lane (one transmit, one receive channel).
DS64BR111SQ features a powerful 4-stage continuous time linear equalizer (CTLE) to provide a boost of up to +25 dB at 3.2 GHz and open an input eye that is completely closed due to inter-symbol interference (ISI) induced by the interconnect mediums such as an FR-4 backplane or AWG-30 cables. The transmitter features a programmable output de-emphasis driver with up to -12 dB and allows amplitude voltage levels to be selected from 700 mVp-p to 1200 mVp-p to suit multiple application scenarios.
Specifications
| Type |
Buffer, ReDriver |
| Applications |
SAS, SATA |
| Input |
CML |
| Output |
CML |
| Data Rate (Max) |
6.4Gbps |
| Number of Channels |
2 |
| Delay Time |
230ps |
| Signal Conditioning |
Input Equalization, Output De-Emphasis |
| Capacitance - Input |
10 pF |
| Voltage - Supply |
2.375V ~ 3.6V |
| Current - Supply |
50mA |
| Operating Temperature |
-40°C ~ 85°C |
| Mounting Type |
Surface Mount |
| Package / Case |
24-WFQFN Exposed Pad |
| Supplier Device Package |
24-WQFN (4x4) |
Key Features
Two Channel Repeater for up to 6.4 Gbps
1x Bidirectional Lane
Low 65mW/Channel (Typical) Power Consumption, with Option to Power Down Unused Channels
Advanced Signal Conditioning Features
Receive Equalization up to +25 dB
Transmit De-Emphasis up to -12 dB
Transmit VOD Control: 700 to 1200 mVp-p
< 0.2 UI of Residual DJ at 6.4 Gbps
Programmable via Pin Selection, EEPROM or SMBus Interface
Single Supply Operation Selectable: 2.5V or 3.3v
Flow-Thru Pinout in 4mmx4mm 24-Pin Leadless WQFN Package
>5kV HBM ESD Rating
Industrial -40 to 85°C Operating Temperature Range
Applications
High-Speed Active Copper Cable Modules and FR-4 Backplane in Communication Systems FC, SAS, SATA 3/6 Gbps (with 00B Detection), InfiniBand, CPRI, OBSAI, RXAUI and Many Others
