AMC7834IRTQR Integrated Circuit Chip with 8 Channels 12-bit Resolution and 5V Supply Voltage for Power Amplifier Monitoring

Large Image : AMC7834IRTQR Integrated Circuit Chip with 8 Channels 12-bit Resolution and 5V Supply Voltage for Power Amplifier Monitoring

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	AMC7834IRTQR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	VQFN-56
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

AMC7834IRTQR Integrated Circuit Chip with 8 Channels 12-bit Resolution and 5V Supply Voltage for Power Amplifier Monitoring

Description

Part Number:	AMC7834IRTQR	Number Of Channels:	8
Resolution:	12 Bits	Data Interface:	SPI
Voltage - Supply:	5V	Operating Temperature:	-40°C ~ 125°C
Highlight:	8 Channels Integrated Circuit Chip , 12-bit Resolution Power Amplifier Monitor , 5V Supply Voltage Analog Monitoring IC

AMC7834IRTQR Integrated Circuit Chip Power Amplifier Monitor VQFN56 Analog Monitoring

The AMC7834IRTQR is a highly-integrated, low-power, analog monitoring and control solution for power-amplifier (PA) biasing with temperature, current and voltage supervision capabilities.

This IC integrates a multi-channel 12-bit ADC, eight 12-bit DACs, four high-side current-sense amplifiers, temperature sensors, GPIO ports, and an internal reference. Its high level of integration reduces component count and simplifies PA-biasing system designs.

Specifications

Type	Audio Amp
Number of Channels	8
Resolution (Bits)	12 b
Data Interface	SPI
Voltage Supply Source	Analog and Digital
Voltage - Supply	5V
Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	56-VFQFN Exposed Pad
Supplier Device Package	56-QFN (8x8)

Key Features

Eight monotonic 12-bit DACs with programmable ranges:
- Four bipolar DACs: -4 to 1 V, -5 to 0 V, and 0 to 5 V
- Four unipolar DACs: 0 to 5 V, and 2.5 to 7.5 V
- High current drive capability: up to ±10 mA
- Selectable clamp voltage
Multi-channel 12-bit SAR ADC with four external analog inputs (0 to 2.5 V range) and four internal inputs for bipolar DAC monitoring
Four high-side current-sense amplifiers with common mode voltages: 4 to 60 V
Temperature sensing capabilities with internal sensor and two remote temperature-diode drivers
Internal 2.5 V reference
Four general-purpose I/O ports (GPIOs)
Low-power SPI-compatible serial interface (4-wire mode, 1.7 to 3.6 V operation)
Available in a 56-pin VQFN package

Applications

Communications Infrastructure:
- Cellular Base Stations
- Microwave Backhaul
- Optical Networks
General-Purpose Monitor and Control
Data Acquisition Systems
