IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors

IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors
IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors

Large Image :  IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPD60R600P7
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TO252-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors

Description
Part Number: IPD60R600P7 FET Type: N-Channel
Drain To Source Voltage (Vdss): 600 V Current - Continuous Drain (Id) @ 25°C: 6A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 10V Rds On (Max) @ Id, Vgs: 600mOhm @ 1.7A, 10V
Highlight:

600V Power MOSFET

,

ESD Robustness >2kV MOSFET Transistor

,

N-Channel Integrated Circuit Chip

IPD60R600P7 Integrated Circuit Chip N-Channel 600V CoolMOS™ P7 Power MOSFET Transistors
Product Description
The IPD60R600P7 600V CoolMOS™ P7 superjunction (SJ) MOSFET is the successor to the 600V CoolMOS™ P6 series. It balances high efficiency with ease-of-use in the design process. Featuring best-in-class RonxA and inherently low gate charge (QG) of the CoolMOS™ 7th generation platform, it ensures superior efficiency.
Specifications
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 600 V
Current - Continuous Drain (Id) @ 25°C 6A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 600mΩ @ 1.7A, 10V
Vgs(th) (Max) @ Id 4V @ 80µA
Gate Charge (Qg) (Max) @ Vgs 9 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 363 pF @ 400 V
Power Dissipation (Max) 30W (Tc)
Operating Temperature -40°C ~ 150°C (TJ)
Features
  • Suitable for hard and soft switching (PFC and LLC) due to outstanding commutation ruggedness
  • Significant reduction of switching and conduction losses
  • Excellent ESD robustness >2kV (HBM) for all products
  • Better Rps(on)/package products compared to competition enabled by low Ron*A (below 1Ω*mm²)
Benefits
  • Ease of use and fast design-in through low ringing tendency and usage across PFC and PWM stages
  • Simplified thermal management due to low switching and conduction losses
  • Increased power density solutions enabled by smaller footprint and higher manufacturing quality with >2kV ESD protection
  • Suitable for a wide variety of applications and power ranges
Applications
  • PFC stages, hard switching PWM stages, and resonant switching stages for PC Silverbox, Adapter, LCD & PDP TV, Lighting, Server, Telecom, and UPS
