NGTB40N120FL2WG IGBT Transistor 1200V 80A 535W with Trench Field Stop Technology for Solar Inverters and UPS

Description
Part Number: NGTB40N120FL2WG Collector- Emitter Voltage VCEO Max:: 1.2 KV
Collector-Emitter Saturation Voltage:: 2 V Maximum Gate Emitter Voltage:: - 20 V, 20 V
Continuous Collector Current At 25 C:: 80 A Pd - Power Dissipation:: 535 W
Highlight:

1200V IGBT Transistor

,

80A Integrated Circuit Chip

,

535W Insulated Gate Bipolar Transistor

NGTB40N120FL2WG Integrated Circuit Chip 1200V 80A 535W IGBT Trench Field Stop Transistors
Product Description

The NGTB40N120FL2WG Insulated Gate Bipolar Transistor (IGBT) features a robust and cost-effective Field Stop II Trench construction, delivering superior performance in demanding switching applications. This device combines low on-state voltage with minimal switching loss, making it ideal for UPS and solar applications. Includes a soft and fast co-packaged free-wheeling diode with low forward voltage.

Specifications
IGBT Type Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) 1200 V
Current - Collector (Ic) (Max) 80 A
Current - Collector Pulsed (Icm) 200 A
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 40A
Power - Max 535 W
Switching Energy 3.4mJ (on), 1.1mJ (off)
Input Type Standard
Gate Charge 313 nC
Td (on/off) @ 25°C 116ns/286ns
Test Condition 600V, 40A, 10Ohm, 15V
Reverse Recovery Time (trr) 240 ns
Operating Temperature -55°C ~ 175°C (TJ)
Key Features
  • Extremely Efficient Trench with Field Stop Technology
  • TJmax = 175°C
  • Soft Fast Reverse Recovery Diode
  • Optimized for High Speed Switching
  • 10 s Short Circuit Capability
  • Pb-Free Device
Applications
  • Solar Inverter
  • Uninterruptible Power Supplies (UPS)
  • Welding Equipment
