ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V RS-485/RS-422 Transceiver with 1/5 Unit Load for High-Speed Communication

ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V RS-485/RS-422 Transceiver with 1/5 Unit Load for High-Speed Communication
ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V RS-485/RS-422 Transceiver with 1/5 Unit Load for High-Speed Communication

Large Image :  ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V RS-485/RS-422 Transceiver with 1/5 Unit Load for High-Speed Communication

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ISL3179EIBZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-8
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V RS-485/RS-422 Transceiver with 1/5 Unit Load for High-Speed Communication

Description
Part Number: ISL3179EIBZ Function:: Transceiver
Number Of Drivers:: 1 Driver Number Of Receivers:: 1 Receiver
Data Rate:: 40 Mb/s Operating Supply Current:: 2.6 MA
Highlight:

40Mbps RS-485/RS-422 Transceiver

,

3.3V Integrated Circuit Chip

,

1/5 Unit Load Transceiver

ISL3179EIBZ Integrated Circuit Chip 40Mbps 3.3V Full Fail-Safe RS-485/RS-422 Transceivers
Product Description
ISL3179EIBZ is a high ESD protected, 3.3V powered, single transceiver that meets both the RS-485 and RS-422 standards for balanced communication. Each device features low bus currents (+220µA/-150µA), presenting a "1/5 unit load" to the RS-485 bus. This allows up to 160 transceivers on the network without violating the RS-485 specification's 32 unit load maximum and without requiring repeaters.
Specifications
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 28 mV
Data Rate 40Mbps
Voltage - Supply 3V ~ 3.6V
Operating Temperature -40°C ~ 125°C
Features
  • High ESD protection on RS-485 I/O pins
  • ISL3179E ±16.5kV IEC61000
  • Class 3 HBM level on all other pins (ISL3179E) >9kV
  • Specified for +125°C operation (ISL3179EF Only)
  • High data rates up to 40Mbps
  • 5V tolerant logic inputs
  • 1/5 unit load allows up to 160 devices on the bus
  • Full fail-safe (open, shorted, terminated/undriven) receiver
  • Hot plug - Tx and Rx outputs remain three-state during power-up
  • Low quiescent current 4mA (max)
  • Low current shutdown mode 1µA (max)
  • -7V to +12V common-mode input voltage range
  • Three-state Rx and Tx outputs
  • 16/16.5ns (max) Tx/Rx propagation delays; 1.5ns (max) skew
  • Operates from a single +3.3V supply (10% tolerance)
  • Current limiting and thermal shutdown for driver overload protection
  • Pb-free (RoHS compliant)
Applications
  • Motor controller/position encoder systems
  • Factory automation
  • Field bus networks
  • Security networks
  • Building environmental control systems
