G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating
G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Large Image :  G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: G46M2023201BWEU
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 20POS
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

G46M2023201BWEU G46 Series DisplayPort Connector System 20 Position with DisplayPort 1.4 Compliance 500V AC(RMS) Dielectric Withstanding and 0.5A Current Rating

Description
Part Number: G46M2023201BWEU Conductor Resistance Initial: 10mΩ Max
Contact Current Rating: 0.5A Min Dielectric Withstanding Voltage: 500V AC(RMS)
Package: 20 Position Type: DisplayPort Connector System
Highlight:

DisplayPort 1.4 compliant DisplayPort Connector

,

500V AC(RMS) Dielectric Withstanding DisplayPort Connector

,

0.5A Contact Current Rating DisplayPort Connector

G46M2023201BWEU Connectors G46 Series DisplayPort Connector System 20 Position
Product Description
The G46M2023201BWEU DisplayPort connector system is a scalable solution that transmits 1, 2 or 4 lanes of High-Definition video at 2.7Gb/s per lane up to a maximum of 10.8Gb/s. DisplayPort also allows flexible allocation of available bandwidth between audio and video.
Specifications
Housing High Temperature Thermoplastic, complies with UL 94V-0, Black
Conductor Resistance Initial 10mΩ max.
Shell Initial Contact Resistance 30mΩ max.
Contact Current Rating 0.5A min.
Dielectric Withstanding Voltage 500V AC(RMS)
Humidity 4 cycles between +25°C to +85°C, Relative Humidity 80% to 95%
Thermal Shock 10 cycles between -55˚C to +85˚C
Features
  • DisplayPort 1.4 compliant
  • Protects against ESD (Electrostatic discharge) and EMI (Electromagnetic Interference)
  • Self-latching connector
  • Fully shielded metal shell
  • Fully backward compatible with earlier HDMI
  • Miniaturized option available: Mini DisplayPort
Benefits
  • Performs at 2.7Gb/s per lane backward compatible with earlier DisplayPort product
  • Ensures quick and stable connections
  • Protects against ESD and EMI
  • Meets environmental, health and safety requirements
Applications
  • Datacommunication equipment
  • Telecommunications
  • High End Computers
  • Servers
  • Test Card and Card Extenders
