Part Number:	TPS22916CNYFPR	Type:	Load Switch
Number Of Outputs:	1 Output	Output Current:	2 A
On Resistance - Max:	80 MOhms	Operating Supply Voltage:	1 V To 5.5 V
Highlight:	2A Output Current Load Switch IC , 1V to 5.5V Operating Voltage Power Switch IC , 80mOhms On Resistance Integrated Circuit Chip

TPS22916CNYFPR Integrated Circuit Chip

Single Channel Load Switch IC in DSBGA4 package, featuring a low leakage P-Channel MOSFET for optimal power efficiency.

Product Overview

The TPS22916CNYFPR is a compact single-channel load switch utilizing a low leakage P-Channel MOSFET to minimize power loss. Its advanced gate control design supports operating voltages as low as 1V with minimal increase in ON-resistance and power dissipation.

Technical Specifications

Parameter	Value
Switch Type	General Purpose
Number of Outputs	1
Ratio - Input:Output	1:1
Output Configuration	High Side
Output Type	P-Channel
Voltage - Load	0V ~ 5.5V
Voltage - Supply (Vcc/Vdd)	1V ~ 5.5V
Current - Output (Max)	2A
Rds On (Typ)	200mΩ
Input Type	Non-Inverting
Features	Slew Rate Controlled
Fault Protection	Reverse Current
Operating Temperature	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Supplier Device Package	4-DSBGA
Package / Case	4-XFBGA, DSBGA

Key Features

Input operating voltage range (VIN): 1V-5.5V
Maximum continuous current (IMAX): 2A
ON-resistance (RON): 60mΩ-200mΩ depending on voltage
Ultra-low power consumption in ON/OFF states
Smart ON pin pulldown functionality
Slow Timing (C Version) limits inrush current
Fast timing (B Version) reduces wait time
Always-ON true Reverse Current Blocking (RCB)
Quick Output Discharge (QOD): 150Ω typical
Active low enable option (L versions)

Applications

Wearables Smartphones Tablets Portable Speakers
