ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Large Image : ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	ACPL-247-500E

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SO-16
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

ACPL-247-500E Quad-Channel Phototransistor Optocoupler with 3750 Vrms Isolation Voltage and 50 mA Forward Current

Description

Part Number:	ACPL-247-500E	Number Of Channels:	4 Channel
Isolation Voltage:	3750 Vrms	If - Forward Current:	50 MA
Vf - Forward Voltage:	1.4 V	Pd - Power Dissipation:	170 MW
Highlight:	Quad-Channel Optocoupler , 3750 Vrms Isolation Voltage Optocoupler , 50 mA Forward Current Phototransistor

ACPL-247-500E Integrated Circuit Chip Quad-Channel Half-Pitch Phototransistor Optocoupler

The ACPL-247-500E is a DC-input dual channel half-pitch phototransistor optocoupler featuring two light emitting diodes optically coupled to two separate phototransistors. This component offers input-output isolation voltage rated at 3,000 VRMS and typical response time of 2μs, with minimum CTR of 100% at IF 5mA.

Technical Specifications

Number of Channels	4
Voltage - Isolation	3000Vrms
Current Transfer Ratio (Min)	100% @ 5mA
Current Transfer Ratio (Max)	600% @ 5mA
Turn On / Turn Off Time (Typ)	3µs, 3µs
Rise / Fall Time (Typ)	2µs, 3µs
Input Type	DC
Output Type	Transistor
Voltage - Output (Max)	80V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.2V
Current - DC Forward (If) (Max)	50 mA
Vce Saturation (Max)	400mV
Operating Temperature	-55°C ~ 110°C
Mounting Type	Surface Mount
Package / Case	16-SOIC (0.173", 4.40mm Width)
Supplier Device Package	16-SO

Key Features

Current transfer ratio (CTR): 50% (min) at IF = 5mA, VCE = 5V
High input-output isolation voltage (VISO = 3,000VRMS)
Non-saturated response time (tr: 2μs typ at VCC = 10V, IC = 2mA, RL= 100Ω)
SO package design
CMR 10kV/μs (typical)

Applications

I/O Interface for Programmable controllers and computers
Sequence controllers
System appliances and measuring instruments
Signal transmission between circuits of different potentials and impedances
