RGS80TSX2DHRC11 Integrated Circuit Chip
1200V 40A Field Stop Trench IGBT Transistors for automotive applications with 10µs short-circuit tolerance and built-in FRD.
Product Overview
The RGS80TSX2DHRC11 is a 1200V 40A Field Stop Trench IGBT transistor featuring 10µs short-circuit tolerance, built-in FRD, and TO-247N packaging, specifically designed for automotive applications.
Technical Specifications
| Parameter |
Value |
| IGBT Type |
Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) |
1200 V |
| Current - Collector (Ic) (Max) |
80 A |
| Current - Collector Pulsed (Icm) |
120 A |
| Vce(on) (Max) @ Vge, Ic |
2.1V @ 15V, 40A |
| Power - Max |
555 W |
| Switching Energy |
3mJ (on), 3.1mJ (off) |
| Input Type |
Standard |
| Gate Charge |
104 nC |
| Td (on/off) @ 25°C |
49ns/199ns |
| Test Condition |
600V, 40A, 10Ohm, 15V |
| Reverse Recovery Time (trr) |
198 ns |
| Operating Temperature |
-40°C ~ 175°C (TJ) |
Key Features
- Low Collector - Emitter Saturation Voltage
- Short Circuit Withstand Time 10μs
- Qualified to AEC-Q101 automotive standard
- Built-in Very Fast & Soft Recovery FRD
- Pb-free Lead Plating and RoHS Compliant
Applications
General Inverter for Automotive and Industrial Use
