DRV8302DCA Integrated Circuit Chip Three Phase Gate Driver with 1.7-A Source Current, 8-V to 60-V Operating Supply and Dual Current Shunt Amplifiers

Large Image : DRV8302DCA Integrated Circuit Chip Three Phase Gate Driver with 1.7-A Source Current, 8-V to 60-V Operating Supply and Dual Current Shunt Amplifiers

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	DRV8302DCA

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	HTSSOP-56
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

DRV8302DCA Integrated Circuit Chip Three Phase Gate Driver with 1.7-A Source Current, 8-V to 60-V Operating Supply and Dual Current Shunt Amplifiers

Description

Part Number:	DRV8302DCA	Type::	3 Phase
Output Current::	1.7 A	Operating Supply Current::	15 MA
Minimum Operating Temperature::	- 40 C	Maximum Operating Temperature::	+ 125 C
Highlight:	1.7-A Source Current Gate Driver IC , 8-V to 60-V Operating Supply Integrated Circuit Chip , Dual Current Shunt Amplifiers Three Phase Motor Driver

DRV8302DCA Integrated Circuit Chip

Three Phase Gate Driver With Dual Current Shunt Amplifiers And Buck Regulator

Product Overview

The DRV8302DCA is a high-performance gate driver IC designed for three-phase motor drive applications. It features three half-bridge drivers capable of driving two N-channel MOSFETs each, with robust 1.7-A source and 2.3-A peak current capability.

Technical Specifications

Motor Type	AC, DC \| Brushless DC (BLDC)
Function	Controller - Commutation, Direction Management
Output Configuration	Pre-Driver - Half Bridge (3)
Interface	Parallel
Technology	Power MOSFET
Applications	General Purpose
Voltage Supply	8V ~ 60V
Operating Temperature	-40°C ~ 125°C (TA)

Key Features

8-V to 60-V operating supply voltage range
1.7-A source and 2.3-A sink gate drive current capability
Bootstrap gate driver with 100% duty cycle support
6 or 3 PWM input modes
Dual integrated current shunt amplifiers with adjustable gain and offset
3.3-V and 5-V interface support
Hardware control interface
Comprehensive protection features including programmable dead time control, overcurrent protection, undervoltage lockout, overvoltage lockout, and overtemperature warning/shutdown

Applications

3-Phase BLDC and PMSM Motors
CPAP and Pumps
E-Bikes
Power Tools
Robotics and RC Toys
Industrial Automation

Related Components in Stock

Part Number	Package
R7F101GEE3CNP	HWQFN-40
LCMXO3L-9400C-6BG256C	256-CABGA
LP8865WQDMTRQ1	14-VSON
DAC43902RTERQ1	16-WQFN
LM74930QRGERQ1	24-VQFN
UCC21550BQDWRQ1	16-SOIC
TPS62876B1QWRZVRQ1	24-WQFN
TPS62876QWRZVRQ1	24-WQFN
LM74900QRGERQ1	24-VQFN
F280036PMRQ1	64-LQFP
