BTT6100-2EKA Integrated Circuit Chip Dual Channel Smart High-Side Power Switch with 100mOhm Rds On, 5V ~ 36V Voltage Range, and 2.2A Output Current

Large Image : BTT6100-2EKA Integrated Circuit Chip Dual Channel Smart High-Side Power Switch with 100mOhm Rds On, 5V ~ 36V Voltage Range, and 2.2A Output Current

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	BTT6100-2EKA

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	PG-DSO-14
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

BTT6100-2EKA Integrated Circuit Chip Dual Channel Smart High-Side Power Switch with 100mOhm Rds On, 5V ~ 36V Voltage Range, and 2.2A Output Current

Description

Part Number:	BTT6100-2EKA	Output Type:	N-Channel
Current - Output (Max):	2.2A	Rds On (Typ):	100mOhm
Voltage - Load:	5V ~ 36V	Operating Temperature:	-40°C ~ 150°C (TJ)
Highlight:	100mOhm Rds On Integrated Circuit Chip , 5V ~ 36V Voltage Range Smart High-Side Power Switch , 2.2A Output Current Dual Channel Power Switch

BTT6100-2EKA Integrated Circuit Chip Dual Channel Smart High-Side Power Switch PG-DSO-14

The BTT6100-2EKA is a 100 mΩ dual channel Smart High-Side Power Switch housed in a PG-DSO-14-40 EP (Exposed Pad) package. This advanced component delivers comprehensive protective functions and diagnostic capabilities, featuring an N-channel vertical power MOSFET with integrated charge pump. Manufactured using Smart6 HV technology, it's specifically engineered for demanding automotive applications including driving lamps up to 1x P21W 24V or 1x R10W 12V, as well as LED systems in harsh environments.

Technical Specifications

Specification	Details
Switch Type	General Purpose
Number of Outputs	2
Ratio - Input:Output	1:1
Output Configuration	High Side
Output Type	N-Channel
Interface	On/Off
Voltage - Load	5V ~ 36V
Voltage - Supply (Vcc/Vdd)	Not Required
Current - Output (Max)	2.2A
Rds On (Typ)	100mOhm
Input Type	Non-Inverting
Fault Protection	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-DSO-14-40-EP
Package / Case	14-SOIC (0.154", 3.90mm Width) Exposed Pad

Key Features

Dual channel device design
Very low stand-by current consumption
3.3 V and 5 V compatible logic inputs
Electrostatic discharge protection (ESD)
Optimized electromagnetic compatibility
Logic ground independent from load ground
Very low power DMOS leakage current in OFF state

Application Areas

Suitable for resistive, inductive and capacitive loads
Replaces electromechanical relays, fuses and discrete circuits
Ideal for loads with high inrush current, such as lamps
Optimized for 24V Trucks and Transportation Systems
