BTT6050-2ERA Dual-Channel 50mΩ Smart High-Side Power Switch Integrated Circuit Chip 5V ~ 36V PROFET®

Large Image : BTT6050-2ERA Dual-Channel 50mΩ Smart High-Side Power Switch Integrated Circuit Chip 5V ~ 36V PROFET®

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	BTT6050-2ERA

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	PG-TDSO-14
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

BTT6050-2ERA Dual-Channel 50mΩ Smart High-Side Power Switch Integrated Circuit Chip 5V ~ 36V PROFET®

Description

Part Number:	BTT6050-2ERA	IL Nominal Current:	4 A
Load Current:	3 A	Rds On (Typ):	50mOhm
Voltage - Load:	5V ~ 36V	Operating Temperature:	-40 °C To 150 °C
Highlight:	Dual-Channel Power Switch , 50mΩ Integrated Circuit Chip , 5V ~ 36V PROFET®

BTT6050-2ERA Integrated Circuit Chip Dual-Channel Smart High-Side Power Switch PG-TDSO-14

BTT6050-2ERA is a 50mΩ dual channel Smart High-Side Power Switch, embedded in a PG-TDSO-14, Exposed Pad package, with protective functions and diagnosis.

Specifications

Parameter	Value
Series	PROFET®
Switch Type	General Purpose
Number of Outputs	2
Ratio - Input:Output	1:1
Output Configuration	High Side
Output Type	N-Channel
Interface	On/Off
Voltage - Load	5V ~ 36V
Voltage - Supply (Vcc/Vdd)	Not Required
Current - Output (Max)	3A
Rds On (Typ)	50mOhm
Input Type	Non-Inverting
Fault Protection	Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-TDSO-14-31
Package / Case	14-SOIC (0.154", 3.90mm Width) Exposed Pad

Key Features

Two channel device
Very low stand-by current
3.3V and 5V compatible logic inputs
Electrostatic discharge protection (ESD)
Optimized electromagnetic compatibility
Logic ground independent of load ground
Low power DMOS leakage I in OFF state
RoHS compliant and AEC qualified

Applications

Domain controller for ADAS & autonomous driving
Automotive secondary power distribution unit
Automotive body control module (BCM)
EV traction inverter
Battery energy storage (BESS)
