TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics

TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics
TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics

Large Image :  TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TLE4263GS
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-DSO-8
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Dropout Voltage Regulator for Automotive Electronics

Description
Part Number: TLE4263GS Output Voltage: 5 V
Output Current: 200 MA Dropout Voltage: 350 MV
Ib - Input Bias Current: 900 UA Voltage Regulation Accuracy: 2 %
Highlight:

5V Output Integrated Circuit Chip

,

Low Dropout Voltage Voltage Regulator

,

Automotive Electronics OPTIREG™

TLE4263GS Integrated Circuit Chip 5V OPTIREG™ Low Drop Voltage Regulator PG-DSO-8
The TLE4263GS is a 5V low drop voltage regulator in a PG-DSO-8 package designed for demanding automotive and industrial applications. This OPTIREG™ series IC regulates input voltage (6V to 45V) to a stable 5.0V output with exceptional precision and reliability.
Product Overview
This voltage regulator supports output currents exceeding 200mA and features comprehensive protection including short-circuit proof operation with temperature protection. It generates a reset signal when output voltage drops below 4.5V (adjustable to 3.5V) with reset delay set by an external capacitor. Integrated watchdog logic supervises microcontrollers, and an inhibit input switches off the IC, reducing current consumption from 900μA to 0μA.
Technical Specifications
Parameter Specification
Series OPTIREG™
Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 45V
Voltage - Output (Min/Fixed) 5V
Voltage Dropout (Max) 0.5V @ 150mA
Current - Output 200mA
Current - Quiescent (Iq) 50 µA
Current - Supply (Max) 23 mA
PSRR 54dB (100Hz)
Control Features Reset, Watchdog
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Operating Temperature -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package PG-DSO-8-18
Key Features
  • Output Voltage Tolerance ≤ ± 2%
  • 200 mA Output Current Capability
  • Low-drop Voltage
  • Very low Standby Current Consumption
  • Over Temperature Protection
  • Reverse Polarity Protection
  • Adjustable Reset Threshold
  • Watchdog functionality
  • Wide Temperature Range operation
  • Suitable for automotive electronics
  • Green Product (RoHS compliant)
Primary Applications
  • Automotive systems
  • Seat control modules
  • High-performance cockpit controllers
