RS256M32LS4D1BNR-46BT Memory IC Chip 1Gbit LPDDR4 SDRAM Memory Chip FBGA200
RS256M32LS4D1BNR-46BT Memory IC Chip 1Gbit LPDDR4 SDRAM Memory Chip FBGA200
Product Description
RS256M32LS4D1BNR-46BT is a 1Gbit LPDDR4 SDRAM memory chip housed in an FBGA-200 package. This chip features a memory capacity of 1Gbit, configured as 256Mb x 32-bit (dual channel, 16-bit I/O per channel), supporting the DDR architecture.
Specifications
| Memory Capacity |
1Gbit |
| Configuration |
256Mb x 32-bit |
| Architecture |
DDR |
| Core Voltage (VDD1) Range |
1.70V to 1.95V (typical 1.80V) |
| I/O Voltage (VDD2 and VDDQ) Range |
1.06V to 1.17V (typical 1.10V) |
| Operating Frequency Range |
10MHz to 2133MHz (PIN rate 20Mbp/s to 4266Mbp/s) |
| Operating Temperature Range |
-25°C to +85°C |
| Data Transfer Rate (Max) |
Up to 8.53 GB/s (per channel) |
Key Features
- 16N prefetch architecture
- Programmable read/write latency (RL/WL)
- Burst length (BL) configurable to 16 or 32
- Partial array self-refresh (PASR) capability
- Data transfer rate up to 8.53 GB/s per channel
- Packaged as a 200-ball FBGA (10mm x 15mm x 1.02mm maximum)
- Compliant with ROHS standards
Applications
RS256M32LS4D1BNR-46BT is suitable for embedded systems or consumer electronics requiring high-density, low-power memory.
