ADG659YRUZ 4-Channel Low Voltage CMOS Analog Multiplexer IC Chip with 75 Ohms On Resistance

Description

Part Number:	ADG659YRUZ	Number Of Channels::	4 Channel
Configuration::	2 X 4:1	Supply Voltage - Min::	2 V
Supply Voltage - Max::	12 V	On Resistance - Max::	75 Ohms
Highlight:	4-Channel CMOS Analog Multiplexer , Low Voltage IC Chip , 75 Ohms On Resistance Integrated Circuit Chip

ADG659YRUZ Integrated Circuit Chip

4-Channel Low Voltage CMOS Analog Multiplexer

The ADG659YRUZ is a low voltage, CMOS analog multiplexer featuring eight single channels and four differential channels. This device switches one of four differential inputs to a common differential output based on 2-bit binary address lines A0 and A1. An EN input enables or disables the device, switching all channels off when disabled.

Technical Specifications

Parameter	Value
Switch Circuit	SP4T
Multiplexer/Demultiplexer Circuit	4:1
Number of Circuits	2
On-State Resistance (Max)	75Ω
Channel-to-Channel Matching (ΔRon)	1.3Ω
Voltage - Supply, Single (V+)	2V ~ 12V
Voltage - Supply, Dual (V±)	±2V ~ 6V
Switch Time (Ton, Toff) (Max)	115ns, 45ns
-3db Bandwidth	400MHz
Charge Injection	2pC
Channel Capacitance (CS(off), CD(off))	4pF, 12pF
Current - Leakage (IS(off)) (Max)	200pA
Crosstalk	-90dB @ 1MHz
Operating Temperature	-40°C ~ 125°C (TA)

Key Features

±2 V to ±6 V dual supply operation
2 V to 12 V single supply operation
Automotive temperature range: -40°C to +125°C
Low leakage currents: <0.1 nA
45 Ω on resistance over full signal range
Rail-to-rail switching operation
Differential 4-to-1 multiplexer configuration
Available in 16-lead LFCSP/TSSOP/QSOP packages
Typical power consumption <0.1 μW
TTL/CMOS compatible inputs
Package upgrades to 74HC4051/74HC4052 and MAX4051/MAX4052/MAX4581/MAX4582

Product Highlights

The ADG658 and ADG659 deliver high performance with full specification and guarantee across ±5 V, +5 V, and +3 V supply rails. Designed for automotive applications with extended temperature range operation, these devices feature exceptionally low power consumption and are available in compact 16-lead 4 mm * 4 mm LFCSP packages, 16-lead TSSOP package, and 16-lead QSOP package.

Applications

Automotive systems and applications
Automatic test equipment
Data acquisition systems
Battery-powered systems
Communication systems
Audio and video signal routing
Relay replacement solutions
Sample-and-hold systems
Industrial control systems
