TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range

TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range
TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range

Large Image :  TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TPS560430XDBVR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOT-23-6
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

TPS560430XDBVR Integrated Circuit Chip 600mA Synchronous Step-Down Converter with 1.1MHz Switching Frequency and 4V to 36V Input Range

Description
Part Number: TPS560430XDBVR Output Current: 600 MA
Switching Frequency: 1.1 MHz Quiescent Current: 80 UA
Voltage - Output (Max): 34.2V Operating Temperature: -40°C ~ 125°C (TJ)
Highlight:

600mA Output Current Integrated Circuit Chip

,

1.1MHz Switching Frequency Synchronous Step-Down Converter

,

4V to 36V Input Range DC-DC Converter

TPS560430XDBVR Integrated Circuit Chip
600mA Synchronous Step-Down Converter in SOT-23-6 Package
Product Overview
The TPS560430XDBVR is an easy-to-use synchronous step-down DC-DC converter capable of driving up to 600mA load current. With a wide input range of 4V to 36V, this device is suitable for a wide range of applications from industrial to automotive for power conditioning from unregulated sources.
Key Specifications
Series SIMPLE SWITCHER®
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type PFM
Number of Outputs 1
Voltage - Input (Min) 4V
Voltage - Input (Max) 36V
Voltage - Output (Min/Fixed) 1V
Voltage - Output (Max) 34.2V
Current - Output 600mA
Frequency - Switching 1.1MHz
Synchronous Rectifier Yes
Operating Temperature -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-23-6
Supplier Device Package SOT-23-6
Key Features
  • Rugged Industrial Configuration: 4V to 36V input voltage range, 600mA continuous output current, 60ns minimum switching-on time, 98% maximum duty cycle, pre-biased output startup support, short circuit protection with hiccup mode, ±1.5% tolerance voltage reference, precision enable
  • Compact Solution & Ease of Use: Integrated synchronous rectification, internal compensation, SOT-23-6 package
  • Multiple Configuration Options: 1.1MHz and 2.1MHz frequency options, PFM and Forced PWM (FPWM) options, fixed 3.3V output option
  • Custom design capability using TPS560430 with WEBENCH® Power Designer
Applications
  • Grid Infrastructure: Advanced Metering Infrastructure
  • Motor Drive: AC Inverters, VF Drives, Servos, Field Actuators
  • Factory and Building Automation: PLC, Industrial PC, Elevator Control, HVAC Control
  • Aftermarket Automotive: Camera Systems
  • General Purpose Wide VIN Power Supplies
