AD5172BRMZ2.5 Dual One-Time Programmable Digital Potentiometer I2C MSOP-10 Integrated Circuit Chip

The AD5172BRMZ2.5 is a dual-channel, 256-position digital potentiometer with one-time programmable memory in a MSOP-10 package. Each channel performs the same adjustment function as a mechanical trimmer or variable resistor, with solid state reliability and a low temperature coefficient.

A fuse link stores the final resistance setting permanently, which gives a set-and-forget behaviour at lower cost than an EEMEM based part. Adjustment over the 2-wire interface is unlimited until the OTP command is issued, and the OTP value can be overwritten while the preset remains user defined.

End-to-end resistance for this part number is 2.5 kilohm, and both wiper registers can be read back as well as written. Power-on presets both channels to midscale with a typical 5 microsecond settling time, so the circuit starts from a defined state.

The part is fixed-address on the bus, so it can be paired with a second device using the alternate address option. Supply current is 6 microamp maximum, which suits battery powered instruments and always-on trim circuits.

The AD5172BRMZ2.5 operates from a single 2.7 V to 5.5 V supply over -40 to +125 degree C, is RoHS compliant and lead free, and ships with full traceability. Samples and volume pricing are available on request.

• Dual-channel digital potentiometers
• One-time programmable (OTP) set-and-forget resistance setting
• OTP is a low cost alternative to EEMEM
• Unlimited adjustments before OTP activation
• OTP overwrite allows dynamic adjustment with a user defined preset
• End-to-end resistance 2.5 kilohm
• Full read and write of the wiper register
• Power-on preset to midscale
• Fast settling time 5 microseconds typical at power-up
• 2-wire I2C-compatible digital interface
• Single supply 2.7 V to 5.5 V
• Low temperature coefficient 35 ppm per degree C
• Supply current 6 microamp maximum
• Wide -40 to +125 degree C operating range
• Compact MSOP-10 package

• Mechanical trimmer replacement
• Factory calibration stored permanently at test
• Gain and offset trimming
• Programmable filters and reference setting
• Portable instrumentation

Typical use is digitally controlled resistance and divider trimming in surface mount assemblies.
