IRFP4368PBF Integrated Circuit Chip
75V Single N-Channel StrongIRFET™ Power MOSFET Transistors in TO-247 Package
Product Overview
The IRFP4368PBF StrongIRFET™ power MOSFET family is optimized for low RDS(on) and high current capability. These devices are ideal for low frequency applications requiring performance and ruggedness. The comprehensive portfolio addresses a broad range of applications including DC motors, battery management systems, inverters, and DC-DC converters.
Technical Specifications
| Parameter |
Value |
| FET Type |
N-Channel |
| Technology |
MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) |
75 V |
| Current - Continuous Drain (Id) @ 25°C |
195A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) |
10V |
| Rds On (Max) @ Id, Vgs |
1.85mOhm @ 195A, 10V |
| Vgs(th) (Max) @ Id |
4V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs |
570 nC @ 10 V |
| Vgs (Max) |
±20V |
| Input Capacitance (Ciss) (Max) @ Vds |
19230 pF @ 50 V |
| Power Dissipation (Max) |
520W (Tc) |
| Operating Temperature |
-55°C ~ 175°C (TJ) |
Key Features
- Optimized for broadest availability
- Product qualification according to JEDEC
- Industry standard through-hole power
- High-current rating
Performance Benefits
- Improved Gate, Avalanche and Dynamic dV/dt Ruggedness
- Fully Characterized Capacitance and Avalanche SOA
- Enhanced body diode dV/dt and dI/dt Capability
- Lead-Free construction
Applications
- High Efficiency Synchronous Rectification in SMPS
- Uninterruptible Power Supply
- High Speed Power Switching
- Hard Switched and High Frequency Circuits
