TPS562206DRLR Integrated Circuit Chip 4.2V to 17V Input 2A Output Current 600kHz Switching Frequency Synchronous Buck Converter

Description

Part Number:	TPS562206DRLR	Output Voltage::	600 MV To 7 V
Output Current::	2 A	Number Of Outputs::	1 Output
Input Voltage - Min::	4.2 V	Input Voltage - Max::	17 V
Quiescent Current::	110 UA	Switching Frequency::	600 KHz
Highlight:	4.2V to 17V Input Integrated Circuit Chip , 2A Output Current Synchronous Buck Converter , 600kHz Switching Frequency IC Chip

TPS562206DRLR Integrated Circuit Chip 4.2V To 17V 2A Synchronous Buck Converter

The TPS562206DRLR is a simple, easy-to-use 2A synchronous buck converter in a compact SOT563 package. Designed for minimal external component requirements, this device delivers efficient power conversion with low standby current consumption.

Product Specifications

Function	Step-Down
Output Configuration	Positive
Topology	Buck
Output Type	Adjustable
Number of Outputs	1
Voltage - Input (Min)	4.2V
Voltage - Input (Max)	17V
Voltage - Output (Min/Fixed)	0.6V
Voltage - Output (Max)	7V
Current - Output	2A
Frequency - Switching	600kHz
Synchronous Rectifier	Yes
Operating Temperature	-40°C ~ 125°C (TJ)

Key Features

Wide Application Configuration: Input voltage range: 4.2V to 17V, Output voltage range: 0.6V to 7V, Reference voltage: 0.6V with ±1.5% accuracy at 25°C and ±2% accuracy from -40°C to 125°C
High-Efficiency Design: Integrated 100mΩ and 55mΩ FETs, 600kHz switching frequency, up to 95% maximum duty cycle operation, 1.4ms fixed soft-start time
User-Friendly Operation: FCCM mode at light loading, D-CAP3™ control mode with fast transient response, supports start-up with prebiased output
Comprehensive Protection: Non-latch OT and UVLO protection, cycle-by-cycle overcurrent limit, hiccup mode for UV protection
Compact Package: SOT563 package measuring 1.6mm * 1.6mm, operating junction temperature range: -40°C to 125°C
Design Support: Create custom designs using the TPS562206 with WEBENCH® Power Designer

Applications

Television systems, Digital set-top boxes (STB), Building automation systems, Broadband fixed line access equipment
