BTS50085-1TMA Integrated Circuit Chip PROFET Smart High Side High Current Power Switch
BTS50085-1TMA is a high side power switch with integrated vertical power FET, providing embedded protection and diagnostic functions.
Product Specifications
| Parameter |
Value |
| Series |
PROFET® |
| Switch Type |
General Purpose |
| Number of Outputs |
1 |
| Ratio - Input:Output |
1:1 |
| Output Configuration |
High Side |
| Output Type |
N-Channel |
| Interface |
On/Off |
| Voltage - Load |
5V ~ 58V |
| Voltage - Supply (Vcc/Vdd) |
Not Required |
| Current - Output (Max) |
38A |
| Rds On (Typ) |
7.2mOhm |
| Input Type |
Non-Inverting |
| Features |
Auto Restart |
| Fault Protection |
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Operating Temperature |
-40°C ~ 150°C (TJ) |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
PG-TO220-7-4 |
| Package / Case |
TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
Key Features
- Overload protection
- Current limitation
- Short circuit protection
- Over temperature protection
- Over voltage protection (including load dump)
- Clamp of negative voltage at output
- Fast deenergizing of inductive loads
- Low ohmic inverse current operation
- Diagnostic feedback with load current sense
- Open load detection via current sense
- Loss of Vbb protection
- Electrostatic discharge (ESD) protection
Applications
Automotive secondary power distribution unit, Internal combustion drivetrain systems, Consumer electronics, Hydrogen electrolysis, Home and building automation
