AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed

AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed
AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed

Large Image :  AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: AS5040-ASST
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SSOP-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

AS5040-ASST Sensor IC Rotary Sensor with 10-bit Resolution 360° Operating Angle and 30,000 RPM Max Rotation Speed

Description
Part Number: AS5040-ASST Operating Supply Current: 16 MA
Accuracy Typ.: 0.5 ° Operating Angle: 360 Deg
Resolution: 10 Bit Rotation Speed - Max: 30000 Rpm
Highlight:

10-bit resolution Sensor IC

,

360° operating angle Rotary Sensor

,

30

AS5040-ASST Sensor IC Rotary Sensor 10Bit 360º Programmable Magnetic Rotary Encoder
AS5040-ASST Sensor IC Rotary Sensor 10Bit 360º Programmable Magnetic Rotary Encoder
Product Description
The AS5040-ASST is a 10-bit rotary position sensor designed for absolute angular measurement with incremental output over a full 360° rotation. Utilizing contactless magnetic sensor technology, this encoder is ideal for on-axis applications where a simple 2-pole magnet rotates above or below the sensor IC. The zero position can be programmed directly into the device, providing precise angular position measurement with 10-bit resolution (1024 positions per revolution). Digital output is available through both serial interface (SSI) and PWM output signal.
Specifications
Encoder Type Magnetic
Output Type PWM
Pulses per Revolution 512
Voltage - Supply 4.5V ~ 5.5V
Actuator Type External Magnet, Not Included
Detent No
Built in Switch No
Mounting Type Surface Mount
Termination Style SMD (SMT) Tab
Key Features
  • Contactless high resolution rotational position encoding over 360 degrees
  • User-programmable resolution, pole pairs and zero position
  • Serial communication interface (SSI)
  • 10-bit pulse width modulated (PWM) output
  • Quadrature A/B and Index output signal
  • Step/Direction and Index output signal
  • 3-Phase commutation for brushless DC motors
  • Rational speeds up to 30,000 rpm
  • Failure detection mode for magnet placement monitoring and power supply loss
  • Serial read-out of multiple interconnected devices using daisy chain mode
  • Push button functionality detects movement of magnet in Z-axis
  • SSOP 16 (5.3mm x 6.2mm) package
  • Wide temperature range: -40°C to 125°C
Applications
The AS5040 is ideal for:
  • Industrial Applications: Contactless rotary position sensing, Robotics, Brushless DC motor commutation, Power tools
  • Automotive Applications: Steering wheel position sensing, Gas pedal position sensing, Transmission gearbox encoder, Headlight position control, Power seat position indicator
  • Office equipment: printers, scanners, copiers
  • Replacement of optical encoders
  • Front panel rotary switches
  • Replacement of potentiometers
