TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode

TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode
TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode

Large Image :  TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TJA1042TK
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: HVSON-8
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode

Description
Part Number: TJA1042TK Data Rate:: 5 Mb/s
Number Of Drivers:: 1 Driver Number Of Receivers:: 1 Receiver
Supply Voltage - Min:: 4.5 V Supply Voltage - Max:: 5.5 V
Highlight:

TJA1042TK high-speed CAN transceiver

,

CAN transceiver with standby mode

,

integrated circuit chip CAN transceiver

TJA1042TK Integrated Circuit Chip High-Speed CAN Transceiver With Standby Mode
The TJA1042TK high-speed CAN transceiver provides an interface between a controller area network (CAN) protocol controller and the physical two-wire CAN bus. This transceiver is specifically designed for high-speed CAN applications in the automotive industry, delivering differential transmit and receive capability to microcontrollers with CAN protocol controllers.
Specifications
Protocol CANbus
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 120 mV
Data Rate 5Mbps
Voltage - Supply 4.5V ~ 5.5V
Operating Temperature -40°C ~ 150°C
Grade Automotive
Key Features
General Features
  • Fully ISO 11898-2:2016, SAE J2284-1 to SAE J2284-5 and SAE J1939-14 compliant
  • Timing guaranteed for data rates up to 5 Mbit/s in the CAN FD fast phase
  • Suitable for 12 V and 24 V systems
  • Low Electromagnetic Emission (EME) and high Electromagnetic Immunity (EMI)
  • Variants with VIO pin allow direct interfacing with 3.3 V to 5 V microcontrollers
  • Shorter propagation delay on TJA1042B and TJA1042C variants supports larger network topologies
  • SPLIT voltage output on TJA1042T and TJA1042CT for stabilizing recessive bus level
  • Dark green product (halogen free and RoHS compliant)
  • AEC-Q100 qualified
Predictable and Fail-Safe Behavior
  • Very low-current Standby mode with host and bus wake-up capability
  • Functional behavior predictable under all supply conditions
  • Transceiver disengages from bus when not powered up (zero loads)
  • Transmit Data (TXD) dominant time-out function
  • Bus-dominant time-out function in Standby mode
  • Undervoltage detection on pins VCC and VIO
Protection Features
  • High ESD handling capability on bus pins (±8 kV)
  • High voltage robustness on CAN pins (±58 V)
  • Bus pins protected against transients in automotive environments
  • Thermally protected
Applications
  • Automotive systems
  • Hybrid Electric Vehicle (HEV) Applications
  • Tire Pressure Monitoring Systems (TPMS)
