ADTL084ARUZ Integrated Circuit Chip Low Cost JFET Input Operational Amplifiers
The ADTL084ARUZ represents a significant advancement in JFET input operational amplifiers, delivering superior performance compared to traditional TL08x devices. This integrated circuit chip offers enhanced specifications including reduced noise, lower offset voltage, improved temperature stability, and minimized bias current.
Performance Advantages
The ADTL084ARUZ family provides superior common-mode rejection and faster slew rates, making these operational amplifiers ideal for demanding applications in process control, industrial instrumentation, active filtering, data conversion, buffering, and power control systems.
Technical Specifications
| Parameter |
Specification |
| Amplifier Type |
J-FET |
| Number of Circuits |
4 |
| Slew Rate |
20V/µs |
| Gain Bandwidth Product |
5 MHz |
| Input Bias Current |
2 pA |
| Input Offset Voltage |
1.5 mV |
| Supply Current |
1.2mA (x4 Channels) |
| Output Current per Channel |
27 mA |
| Minimum Supply Voltage |
8 V |
| Maximum Supply Voltage |
36 V |
| Operating Temperature |
-40°C ~ 125°C |
Key Features
- TL082/TL084 compatible design
- Low input bias current: 10 pA maximum
- Offset voltage options: 5.5 mV maximum (ADTL082A/ADTL084A) or 9 mV maximum (ADTL082J/ADTL084J)
- ±15 V operation capability
- Low noise: 16 nV/√Hz
- Wide bandwidth: 5 MHz
- Fast slew rate: 20 V/μs
- High CMRR: 80 dB minimum
- Low total harmonic distortion: 0.001%
- Efficient supply current: 1.2 mA typical
- Unity-gain stable operation
Application Areas
- General-purpose amplification circuits
- Power control and monitoring systems
- Active filter designs
- Industrial and process control equipment
- Data acquisition systems
- Sample and hold circuits
- Integrator applications
- Input buffering solutions
