LTC3265EFE Low Noise Dual Supply IC Chip with 50mA Output Current and Boost Charge Pump

Large Image : LTC3265EFE Low Noise Dual Supply IC Chip with 50mA Output Current and Boost Charge Pump

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	LTC3265EFE

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TSSOP-EP-20
Delivery Time:	3-5 work days
Payment Terms:	TT
Supply Ability:	10000 Pieces per Day

Contact Now

LTC3265EFE Low Noise Dual Supply IC Chip with 50mA Output Current and Boost Charge Pump

Description

Part Number:	LTC3265EFE	Output Current::	50 MA
Number Of Outputs::	2 Output	Input Voltage - Min::	4.5 V
Input Voltage - Max::	32 V	Quiescent Current::	3 MA
Highlight:	Low Noise IC Chip , Dual Supply Integrated Circuit Chip , 50mA Output Current Power Supply IC

LTC3265EFE Integrated Circuit Chip Low Noise Dual Supply With Boost And Inverting Charge Pumps

The LTC3265 is a low noise dual polarity output power supply that integrates a boost charge pump, an inverting charge pump, and two low noise positive and negative LDO post regulators. The boost charge pump powers the positive LDO post regulator while the inverting charge pump powers the negative LDO regulator. Each LDO can deliver up to 50mA of output current, with adjustable output voltages via external resistor dividers.

Specifications

Function	Ratiometric
Output Configuration	Positive and Negative (Dual Rail)
Topology	Charge Pump
Output Type	Fixed
Number of Outputs	2
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	32V
Voltage - Output (Min/Fixed)	-Vin, 2Vin
Current - Output	100mA
Frequency - Switching	50kHz ~ 500kHz
Synchronous Rectifier	No
Operating Temperature	-40°C ~ 125°C (TJ)

Key Features

Boost Charge Pump Generates 2 • VIN_P (VIN_P Range: 4.5V to 16V)
Inverting Charge Pump Generates -VIN_N (VIN_N Range: 4.5V to 32V)
Low Noise Positive LDO Post Regulator Up to 50mA
Low Noise Negative LDO Post Regulator Up to 50mA
135μA Quiescent Current in Burst Mode® Operation with Both LDO Regulators On
50kHz to 500kHz Programmable Oscillator Frequency
Stable with Ceramic Capacitors
Short-Circuit/Thermal Protection
Low Profile 3mm * 5mm 18-Lead DFN and Thermally Enhanced 20-Lead TSSOP Packages

Applications

Low Noise Bipolar/Inverting Supplies
Industrial/Instrumentation Low Noise Bias Generators
