A8653KLPTR-T Integrated Circuit Chip Synchronous Buck Regulator with 4V to 36V Input Range and Remote Load Regulation for Automotive USB Power Ports

A8653KLPTR-T Integrated Circuit Chip Synchronous Buck Regulator with 4V to 36V Input Range and Remote Load Regulation for Automotive USB Power Ports
A8653KLPTR-T Integrated Circuit Chip Synchronous Buck Regulator with 4V to 36V Input Range and Remote Load Regulation for Automotive USB Power Ports

Large Image :  A8653KLPTR-T Integrated Circuit Chip Synchronous Buck Regulator with 4V to 36V Input Range and Remote Load Regulation for Automotive USB Power Ports

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: A8653KLPTR-T
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

A8653KLPTR-T Integrated Circuit Chip Synchronous Buck Regulator with 4V to 36V Input Range and Remote Load Regulation for Automotive USB Power Ports

Description
Part Number: A8653KLPTR-T Function: Step-Down
Output Type: Adjustable Number Of Outputs: 1
Voltage - Input (Min): 4V Voltage - Input (Max): 36V
Highlight:

Automotive AEC-Q100 qualified Integrated Circuit Chip

,

4V to 36V Input Range Synchronous Buck Regulator

,

Remote Load Regulation USB Power Regulator

A8653KLPTR-T Integrated Circuit Chip Synchronous USB Buck Regulator
The A8653KLPTR-T is a high-output current synchronous buck regulator that provides precise load regulation over wiring harnesses without requiring remote sense lines. This advanced remote load regulation utilizes an integrated open-loop correction scheme that, when combined with known wiring harness resistance, adjusts output voltage based on measured load current and user-programmable gain, achieving ±2% accuracy at 500 mV of correction.
Technical Specifications
Number of Outputs 1
Voltage - Input (Min) 4V
Voltage - Input (Max) 36V
Voltage - Output (Min/Fixed) 3.3V
Voltage - Output (Max) 5.75V
Current - Output 2.5A
Frequency - Switching 100kHz ~ 2MHz
Synchronous Rectifier Yes
Operating Temperature -40°C ~ 150°C (TA)
Grade Automotive
Key Features
  • Automotive AEC-Q100 qualified
  • Cable and wiring drop compensation
  • Dynamic voltage correction with controller
  • Integrated high-side and low-side switching MOSFETs
  • Programmable load-side current limit
  • Maximized duty cycle for low dropout operation
  • Operating input voltage range: 4 V to 36 V
  • UVLO STOP threshold at 2.6 VTYP
  • Withstands surge voltages up to 40 V
  • Continuous loading: 2.6 A for A8653; 1 A for A8652
  • Adjustable switching frequency (fSW): 100 kHz to 2.2 MHz
  • Synchronization to external clock: 100 kHz to 2.2 MHz
  • Frequency dithering for lower EMI signature
  • External adjustable compensation network
  • Stable with ceramic output capacitors
Primary Applications
  • Automotive USB Power Ports
  • Rear Seat Entertainment Systems
  • Navigation Systems
  • Motorcycle Instrument Clusters
Related Electronic Components
Part Number Package
ISO7142CCQDBQQ1 16-SSOP
ISO7331FCQDWQ1 16-SOIC
ISO7340FCQDWQ1 16-SOIC
ISO7721FQDWRQ1 16-SOIC
ISO7820DWWR 16-SOIC
ISO7841DWWR 16-SOIC
ISO7321FCQDQ1 8-SOIC
ISO6721RFBQDRQ1 8-SOIC
OPA814DR 8-SOIC
INA310B4QDGKRQ1 8-TSSOP
INA310A2QDGKRQ1 8-TSSOP
INA310A1QDGKRQ1 8-TSSOP
INA310A5QDGKRQ1 8-TSSOP
INA310B2QDGKRQ1 8-TSSOP
INA310A3QDGKRQ1 8-TSSOP
INA296A2QDDFRQ1 SOT-23-8
INA241A2IDDFR SOT-23-8
INA186A1QDDFRQ1 SOT-23-8
INA190A2QDDFRQ1 SOT-23-8
INA296A2IDDFR SOT-23-8
INA241B3IDDFR SOT-23-8
INA241A5IDDFR SOT-23-8
INA190A4IDCKR 6-TSSOP
INA293A4QDBVRQ1 SOT-23-5
INA281B2QDBVRQ1 SOT-23-5
INA281A5QDBVRQ1 SOT-23-5
INA293B2QDBVRQ1 SOT-23-5
INA240A1QDRQ1 8-SOIC
INA250A4QPWRQ1 16-TSSOP
INA181A2QDBVRQ1 SOT-23-6
Frequently Asked Questions
Are your products original?
Yes, all products are original. Sourcing new original imported components is our primary business focus.
Which Certificates do you have?
We are ISO 9001:2015 Certified Company and member of ERAI.
Can you support small quantity orders or samples? Is the sample free?
Yes, we support sample orders and small quantities. Sample costs vary according to your order requirements or project specifications.
How do you ship my order? Is it safe?
We use express carriers including DHL, FedEx, UPS, TNT, and EMS. We can also use your preferred forwarder. Products are securely packaged to ensure safety, and we assume responsibility for any damage to your order.
What is the lead time?
We can ship stock parts within 5 working days. For items not in stock, we will confirm the lead time based on your order quantity.
