AW87559FCR Integrated Circuit Chip 9V Adaptive Boost TLTR-AGC Smart K Audio Amplifier FCQFN20

Large Image : AW87559FCR Integrated Circuit Chip 9V Adaptive Boost TLTR-AGC Smart K Audio Amplifier FCQFN20

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	AW87559FCR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	FCQFN-20
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

AW87559FCR Integrated Circuit Chip 9V Adaptive Boost TLTR-AGC Smart K Audio Amplifier FCQFN20

Description

Part Number:	AW87559FCR	Boost Type:	Adaptive Boost
PVDD Voltage:	9V	Control Interface:	IIC
Protection:	TLTR AGC	SPK Noise:	45uV@18dB
Highlight:	9V Adaptive Boost Integrated Circuit Chip , TLTR-AGC Audio Amplifier , FCQFN20 Smart K Audio Amplifier

AW87559FCR Integrated Circuit Chip

9V Adaptive Boost TLTR-AGC Smart K Audio Amplifier FCQFN20

Product Overview

The AW87559FCR is a 9V, Adaptive Boost High Efficiency, High PSRR Low Noise Large Volume 2-in-1 TLTR-AGC 5th Generation Smart K Audio Amplifier specifically designed to improve musical output dynamic range and enhance overall sound quality.

Key Specifications

Parameter	Value
Power Supply (Min) (V)	2.8
Power Supply (Max) (V)	5.5
PVDD Voltage (V)	9
Boost Type	Adaptive Boost
PO(W) (8Ω&THD=1%)	4.75W@4.2V
SPK Noise(uV)	45uV@18dB
Protection	TLTR AGC
Control Interface	IIC
RCV mode	YES
RCV Noise(uV)	19uV@9dB 11uV@0dB
Temperature	-40℃~85℃
Package (mm)	FCQFN 2X3-20L

Technical Features

Triple-Level Triple-Rate AGC algorithm for effective noise elimination and pure sound quality
Half wave modulation technology
High efficiency large drive ability Adaptive Boost
Output voltage: 9.0V
Overall efficiency up to 85%
Maximum output Power: 4.75W@8Ω
Support for External VBST Application
High PSRR: 82dB (217Hz)
Low noise performance: 45μV (K Speaker @18dB), 19μV (D Receiver @9dB), 11μV (D Receiver @0dB)
Selectable speaker-guard power level: 0.5W~2W@8ohm, 100mW/step
Speaker & receiver 2-in-1 mode application
Battery tracking AGC selectable for low voltage protection
Shutdown current: 0.1μA
Quiescent current: 6.8mA@3.6V
Super TDD-Noise suppression
Excellent pop-click suppression
Excellent full bandwidth EMI suppression
Support for 1.8V logic I2C control
FCQFN 2.0mm X 3.0mm X 0.55mm-20L package

Applications

Smart Phone
Tablet PC
