MAX6753KA29 Integrated Circuit Chip Processor Reset Supervisor with Windowed Watchdog Timer

Description
Highlight:

MAX6753KA29 Integrated Circuit Chip

,

MAX6753

MAX6753KA29 Processor Reset Supervisor with a Windowed Watchdog and Open-Drain Output

Where several devices share a reset line, the supervisor has to behave well when the supply is only partially up. The MAX6753KA29 drives an open-drain output that stays low from the moment the rail reaches 1 V, so the whole chain is held until the 2.925 V threshold is crossed and the programmed delay has elapsed.

Its watchdog is a window rather than a plain timer. Strobe timing outside the band between the fast and slow edges is treated as a fault, which exposes firmware that is running but no longer doing its job. The fast edge is a divide ratio of 8, 16 or 64 of the slow edge, chosen by the SET0 and SET1 straps.

The slow edge comes from the SWT capacitor, tWD2 = 0.65 x 10^9 x CSWT, and the reset pulse from the SRT capacitor, tRP = 4.94 x 10^6 x CSRT. Because the two are independent, a processor that needs a long reset delay does not force a wide watchdog band.

The output sinks current with a pullup up to 6 V, so the same part can sit on a 3.3 V or 5 V reset bus. Quiescent current is 3.7 microamperes at 2 V and the part is specified to +125 degrees Celsius.

Key Features
  • 2.925 V threshold for 3.3 V rails
  • Windowed watchdog with slow and fast fault detection
  • Fast edge derived at 1/8, 1/16 or 1/64 of the slow edge
  • Open-drain output, pullup up to 6 V
  • Reset asserted from VCC = 1 V upward
  • Separate reset and watchdog timing capacitors
  • 2 percent accuracy, 0.8 percent hysteresis
  • Watchdog off with SET0 high and SET1 low
  • 3.7 microamperes at 2 V in an 8-pin SOT23
  • Lead free and RoHS compliant
Specifications
Product ModelMAX6753
FunctionProcessor reset IC with windowed watchdog timer
Reset OutputOpen drain, active low
Factory Reset Threshold2.925 V typical (2.867 V min, 2.984 V max)
Threshold Accuracy2 percent over temperature
Threshold Hysteresis0.8 percent typical
Watchdog TypeWindowed, flags slow and fast WDI faults
Slow Watchdog WindowCapacitor set, tWD2 = 0.65 x 10^9 x CSWT
Fast Watchdog WindowtWD2 divided by 8, 16 or 64 via SET0 and SET1
Watchdog DisableSET0 high and SET1 low
Reset TimeoutCapacitor set, tRP = 4.94 x 10^6 x CSRT
Manual Reset InputNot included
Adjustable Reset InputNot included
Supply Voltage1.0 V to 5.5 V
Supply Current3.7 microamperes typical at 2 V
Reset Valid Down ToVCC = 1 V, pullup may sit at any voltage up to 6 V
VCC to Reset Delay20 microseconds
Operating Temperature-40 to +125 degrees Celsius
Package8-pin SOT23
Typical Applications
  • Shared reset buses in multi-device boards
  • Telecom line cards
  • Network switches and routers
  • Industrial gateways
  • Battery management systems
  • Medical monitoring equipment
  • Vehicle infotainment units

Reels are packed with desiccant and checked against the purchase order before shipping.
