LTC1865IMS 16-Bit 250Ksps 2-Channel ADC Integrated Circuit Chip in MSOP-10 Package

Large Image : LTC1865IMS 16-Bit 250Ksps 2-Channel ADC Integrated Circuit Chip in MSOP-10 Package

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	LTC1865IMS

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	MSOP-10
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

LTC1865IMS 16-Bit 250Ksps 2-Channel ADC Integrated Circuit Chip in MSOP-10 Package

Description

Part Number:	LTC1865IMS	Resolution:	16 Bit
Number Of Channels::	2 Channel	Sampling Rate::	250 KS/s
Analog Supply Voltage::	5 V	Pd - Power Dissipation:	4.25 MW
Highlight:	16-Bit ADC , 250Ksps ADC , 2-Channel Integrated Circuit Chip

LTC1865IMS Integrated Circuit Chip 16-Bit 250Ksps 2-Channel ADC In MSOP-10 Package

The LTC1865IMS is a high-performance 16-bit A/D converter available in MSOP and SO-8 packages, operating on a single 5V supply. With a sampling rate of 250ksps, it consumes only 850µA supply current. The device automatically powers down between conversions, reducing current consumption at lower speeds. This 16-bit switched capacitor successive approximation ADC includes sample-and-holds and offers a software-selectable 2-channel multiplexer with an adjustable reference pin on the MSOP version.

Specifications

Parameter	Value
Number of Bits	16
Sampling Rate (Per Second)	250k
Number of Inputs	2
Input Type	Single Ended
Data Interface	SPI
Configuration	MUX-S/H-ADC
Ratio - S/H:ADC	1:1
Number of A/D Converters	1
Architecture	SAR
Reference Type	External
Voltage - Supply, Analog	5V
Voltage - Supply, Digital	5V
Operating Temperature	-40°C ~ 85°C

Key Features

16-Bit 250ksps ADCs in MSOP Package
Single 5V Supply Operation
Low Supply Current: 850µA (Typical)
Auto Shutdown Reduces Supply Current to 2µA at 1ksps
True Differential Inputs
1-Channel (LTC1864) or 2-Channel (LTC1865) Versions
SPI/MICROWIRE™ Compatible Serial I/O
16-Bit Upgrade to 12-Bit LTC1286/LTC1298
Pin Compatible with 12-Bit LTC1860/LTC1861
Guaranteed Operation to +125°C (MSOP Package)

Applications

High Speed Data Acquisition
Portable or Compact Instrumentation
Low Power Battery-Operated Instrumentation
Isolated and/or Remote Data Acquisition
