AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier with 1 GHz Gain Bandwidth for 16-Bit Systems

AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier with 1 GHz Gain Bandwidth for 16-Bit Systems
AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier with 1 GHz Gain Bandwidth for 16-Bit Systems

Large Image :  AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier with 1 GHz Gain Bandwidth for 16-Bit Systems

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: AD8021ARMZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: MSOP-8
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier with 1 GHz Gain Bandwidth for 16-Bit Systems

Description
Part Number: AD8021ARMZ Number Of Channels:: 1 Channel
GBP - Gain Bandwidth Product:: 1 GHz SR - Slew Rate:: 130 V/us
Voltage Gain DB:: 86 DB CMRR - Common Mode Rejection Ratio:: - 98 DB
Highlight:

Low Noise Amplifier

,

High Speed Op Amp

,

1 GHz Gain Bandwidth Integrated Circuit Chip

AD8021ARMZ Integrated Circuit Chip Low Noise High Speed Amplifier For 16-Bit Systems
The AD8021ARMZ is a high-performance, high-speed voltage feedback amplifier designed for 16-bit resolution systems. It features both low voltage and low current noise (2.1 nV/√Hz typical and 2.1 pA/√Hz typical) while operating at the lowest quiescent supply current (7 mA @ ±5 V) among today's high-speed, low-noise operational amplifiers. The AD8021ARMZ operates over a wide range of supply voltages from ±2.25 V to ±12 V, as well as from single 5 V supplies, making it ideal for high-speed, low-power instruments. An output disable pin allows further reduction of the quiescent supply current to 1.3 mA.
Specifications
Parameter Value
Amplifier Type Voltage Feedback
Number of Circuits 1
Slew Rate 460V/µs
-3db Bandwidth 560 MHz
Input Bias Current 7.5 µA
Input Offset Voltage 400 µV
Supply Current 7.8mA
Output Current per Channel 70 mA
Minimum Supply Voltage 4.5 V
Maximum Supply Voltage 24 V
Operating Temperature -40°C ~ 85°C
Key Features
  • Low noise performance: 2.1 nV/√Hz input voltage noise and 2.1 pA/√Hz input current noise
  • Custom compensation with constant bandwidth from G = -1 to G = -10
  • High speed operation: 200 MHz (G = -1) and 190 MHz (G = -10)
  • Low power consumption: 34 mW or 6.7 mA typical for 5 V supply
  • Low distortion: -93 dBc second harmonic and -108 dBc third harmonic at fc = 1 MHz
  • DC precision: 1 mV max input offset voltage with 0.5 µV/°C input offset voltage drift
  • Wide supply range from 5 V to 24 V
  • Competitive pricing and small MSOP-8 packaging
Applications
  • ADC preamps and drivers
  • Instrumentation preamps
  • Active filters
  • Portable instrumentation
  • Line receivers
  • Precision instruments
  • Ultrasound signal processing
  • High gain circuits
