Part Number:	AD7682BCPZ	Resolution::	16 Bit
Number Of Channels::	4 Channel	Interface Type::	3-Wire, QSPI, SPI
Sampling Rate::	250 KS/s	SNR - Signal To Noise Ratio::	93.5 DB
Highlight:	16-Bit ADC , 4-Channel PulSAR ADC , 250 kSPS Integrated Circuit Chip

AD7682BCPZ Integrated Circuit Chip

16-Bit 4-Channel 250 kSPS PulSAR ADC in LFCSP-20 Package

Product Overview

The AD7682BCPZ is a 4-channel, 16-bit, charge redistribution successive approximation register (SAR) analog-to-digital converter (ADC) that operates from a single power supply, VDD.

Technical Specifications

Number of Bits	16
Sampling Rate	250 kSPS
Number of Inputs	4
Input Type	Differential, Pseudo-Differential, Single Ended
Data Interface	SPI, DSP
Configuration	MUX-S/H-ADC
Ratio - S/H:ADC	1:1
Number of A/D Converters	1
Architecture	SAR
Reference Type	External, Internal
Voltage Supply (Analog)	2.3V ~ 5.5V
Voltage Supply (Digital)	2.3V ~ 5.5V
Features	Temperature Sensor
Operating Temperature	-40°C ~ 85°C

Key Features

16-bit resolution with no missing codes
4-channel multiplexer with choice of inputs
Support for unipolar single-ended, differential, and pseudobipolar inputs
Throughput: 250 kSPS
INL: ±0.4 LSB typical, ±1.5 LSB maximum (±23 ppm of FSR)
Dynamic range: 93.8 dB
SINAD: 92.5 dB at 20 kHz
THD: −100 dB at 20 kHz
Analog input range: 0 V to VREF with VREF up to VDD
Multiple reference types: internal selectable 2.5V or 4.096V, external buffered, or external
Internal temperature sensor (TEMP)
Channel sequencer, selectable 1-pole filter, busy indicator
No pipeline delay, SAR architecture
Single-supply 2.3V to 5.5V operation with 1.8V to 5.5V logic interface
Serial interface compatible with SPI, MICROWIRE, QSPI, and DSP
Low power dissipation: 3.5 mW at 2.5V/200 kSPS, 12.5 mW at 5V/250 kSPS
Standby current: 50 nA
Available in 20-lead 4mm * 4mm LFCSP package
