MPF42790DRT Integrated Circuit Chip Battery Fuel Gauge for 2 To 16 Stacked Cells Lithium Ion Battery Pack

MPF42790DRT Integrated Circuit Chip Battery Fuel Gauge for 2 To 16 Stacked Cells Lithium Ion Battery Pack
MPF42790DRT Integrated Circuit Chip Battery Fuel Gauge for 2 To 16 Stacked Cells Lithium Ion Battery Pack

Large Image :  MPF42790DRT Integrated Circuit Chip Battery Fuel Gauge for 2 To 16 Stacked Cells Lithium Ion Battery Pack

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MPF42790DRT
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TQFN-32
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

MPF42790DRT Integrated Circuit Chip Battery Fuel Gauge for 2 To 16 Stacked Cells Lithium Ion Battery Pack

Description
Part Number: MPF42790DRT Number Of Cells: 2 ~ 16
Battery Chemistry: Lithium Ion Function: Fuel Gauge
Package: TQFN-32 (4mmx4mm) Operating Temperature: -40°C ~ 85°C (TJ)
Highlight:

2 To 16 Stacked Cells Integrated Circuit Chip

,

Lithium Ion Battery Chemistry Battery Fuel Gauge

,

Fuel Gauge Function Lithium Ion Battery Monitor

MPF42790DRT Integrated Circuit Chip - 2 to 16 Stacked Cells Battery Pack Fuel Gauge
The MPF42790DRT is a comprehensive battery pack fuel gauge solution for lithium-ion battery strings supporting 2 to 16 series cells. This integrated circuit provides detailed status information including state-of-charge (SOC), state-of-health (SOH), remaining runtime, charge time, and instantaneous available power for both individual cells and the complete battery pack.
Product Specifications
Function Fuel Gauge
Battery Chemistry Lithium Ion
Number of Cells 2 ~ 16
Interface I2C
Operating Temperature -40°C ~ 85°C (TJ)
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Supplier Device Package 32-TQFN (4x4)
Key Features
  • Compatible with commonly used battery monitors for up to 16 series cells
  • ±3% State-of-Charge (SOC) accuracy when paired with MP279x battery monitors
  • Provides critical battery information: Pack and Cell SOC, SOH, remaining runtime, charge time, and instantaneous available power
  • Supports a wide variety of lithium cells
  • Adaptive learning capability to refine charge/discharge settings and track cell degradation
  • Provides lifetime logging of key parameters
  • Supports 5-level LED SOC indicator with push-button trigger
  • 2.5V minimum supply voltage
  • Low current consumption: 6μA in disabled mode and 135μA average in operating mode
  • Supports up to 400kHz I2C with CRC for robust communication
  • Compact TQFN-32 (4mmx4mm) package
  • Available in turn-key MPS BMS modules: MBM1xS-P50 and MBM1xS-P100
Applications
Energy Storage System (ESS), E-Bikes, E-Scooters, Light Electric Vehicles (LEVs), Power and Gardening Tools, Battery Backups and UPS
