MPF42792DRT Integrated Circuit Chip Battery Pack Fuel Gauge for 2 to 16 Stacked Cells with TQFN32 Package and Lithium-Ion Battery Monitoring

Large Image : MPF42792DRT Integrated Circuit Chip Battery Pack Fuel Gauge for 2 to 16 Stacked Cells with TQFN32 Package and Lithium-Ion Battery Monitoring

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	MPF42792DRT

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TQFN-32
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

MPF42792DRT Integrated Circuit Chip Battery Pack Fuel Gauge for 2 to 16 Stacked Cells with TQFN32 Package and Lithium-Ion Battery Monitoring

Description

Part Number:

MPF42792DRT

Package:

TQFN32

Minimum Supply Voltage:

2.5V

Type:

2 To 16 Stacked Cells Battery Pack Fuel Gauge

Highlight:

2 to 16 Stacked Cells Battery Pack Fuel Gauge

TQFN32 Package Integrated Circuit Chip

Lithium-Ion Battery Monitoring IC Chip

MPF42792DRT Integrated Circuit Chip - 2 to 16 Stacked Cells Battery Pack Fuel Gauge

The MPF42792DRT is a comprehensive battery pack fuel gauge solution for lithium-ion battery strings supporting 2 to 16 series cells. This integrated circuit provides detailed status monitoring and management capabilities for advanced battery systems.

Product Overview

MPF42792DRT is a drop-in solution that delivers comprehensive status information for lithium-ion battery strings up to 16 series cells. The IC accurately estimates internal state-of-charge (SOC) and state-of-health (SOH) for each individual cell as well as the complete battery pack. It also determines remaining runtime, charge time, and instantaneous available power. On-board memory enables lifetime logging of key battery parameters.

Key Features

Compatible with commonly-used battery monitors for up to 16 series cells
±3% State-of-Charge (SOC) accuracy when paired with MP279x battery monitors
Provides critical battery information including pack and cell SOC/SOH
Calculates remaining runtime, charge time, and instantaneous available power
Supports wide variety of lithium cell chemistries
Adaptive learning refines initial charge/discharge settings and tracks cell degradation
Lifetime logging of key battery parameters
2.5V minimum supply voltage operation
Low current consumption: 6μA in disabled mode, 135μA average in operating mode
Supports up to 400kHz interface with Cyclic Redundancy Check (CRC)
Compact TQFN-32 package (4mm x 4mm)
Available in turn-key MPS BMS modules: MBM1xS-P50 and MBM1xS-P100

Applications

Light Electric Vehicles: Scooters, Bikes, and Golf Carts
Energy Storage Systems: UPS and Renewable Energy
Industrial Automation: Robots, Floor Cleaners, and Forklifts
Power Tools: Cordless Tools and Gardening Equipment
