AD8226ARMZ Instrumentation Amplifier IC Chip with Wide Supply Range Rail-To-Rail Output and 1.5 MHz Bandwidth

Description

Part Number:	AD8226ARMZ	Number Of Channels::	1 Channel
3 DB Bandwidth::	1.5 MHz	SR - Slew Rate::	400 MV/us
CMRR - Common Mode Rejection Ratio::	120 DB	Ib - Input Bias Current::	35 NA
Highlight:	Wide Supply Range Instrumentation Amplifier , Rail-To-Rail Output Integrated Circuit Chip , 1.5 MHz Bandwidth AD8226ARMZ

AD8226ARMZ Integrated Circuit Chip

Low cost, wide supply range instrumentation amplifier with rail-to-rail output that requires only one external resistor to set gains between 1 and 1000.

Product Overview

The AD8226ARMZ is designed to work with various signal voltages, featuring a wide input range and rail-to-rail output that maximizes supply rail utilization. The input range includes the ability to go below the negative supply, enabling amplification of small signals near ground without requiring dual supplies. Operating on supplies ranging from ±1.35V to ±18V for dual supplies and 2.2V to 36V for single supply, this robust amplifier connects effectively to real-world sensors.

With the ability to handle voltages beyond the rails (e.g., ±35V at input with ±5V supply), the AD8226ARMZ is ideal for multichannel, space-constrained industrial applications. Its MSOP package and 125°C temperature rating make it suitable for tightly packed, zero airflow designs.

Technical Specifications

Parameter	Value
Amplifier Type	Instrumentation
Number of Circuits	1
Output Type	Rail-to-Rail
Slew Rate	0.6V/µs
-3dB Bandwidth	1.5 MHz
Input Bias Current	20 nA
Input Offset Voltage	100 µV
Supply Current	350µA
Output Current per Channel	13 mA
Minimum Supply Voltage	2.2 V
Maximum Supply Voltage	36 V
Operating Temperature	-40°C to 125°C

Key Features

Gain set with 1 external resistor
Gain range: 1 to 1000
Input voltage goes below ground
Inputs protected beyond supplies
Very wide power supply range
Single supply: 2.2V to 36V
Dual supplies: ±1.35V to ±18V
Bandwidth (G = 1): 1.5 MHz
CMRR (G = 1): 90 dB minimum for BR models
Input noise: 22 nV/√Hz
Typical supply current: 350 μA
Specified temperature: −40°C to +125°C
8-lead SOIC and MSOP packages

Applications

Industrial process controls
Bridge amplifiers
Medical instrumentation
Portable data acquisition
Multichannel systems
