MAYA-W383-00B Wireless Communication Module
Low-Power Wi-Fi 6/6E and Bluetooth 5.4 Module for IoT Applications
Product Overview
MAYA-W3 modules provide SISO Wi-Fi 6/6E operation with 20 MHz channel width, improved network availability in dense Wi-Fi environments, and MU-MIMO. The modules can work as access point, station, in P2P connections, or combinations of these. Qualified against Bluetooth Core 5.4, MAYA-W3 supports Bluetooth LE, including the use of isochronous channels for LE Audio.
Technical Specifications
| Protocol | 802.11a/b/g/n/ac/ax, Bluetooth v5.4 |
|---|
| Frequency | 2.4GHz, 5GHz, 6GHz |
|---|
| Data Rate | 1Mbps |
|---|
| Power - Output | 20dBm |
|---|
| Sensitivity | -100.5dBm |
|---|
| Serial Interfaces | I2S, PCM, SDIO, UART |
|---|
| Antenna Type | Antenna Not Included |
|---|
| Utilized IC / Part | CYW55513 |
|---|
| Voltage - Supply | 1.8V, 3.3V |
|---|
| Mounting Type | Surface Mount |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
Key Features
- Variants with antenna pins, U.FL connectors, and embedded PCB antenna
- Wi-Fi 6/6E, tri-band, dual-band, and single-band; single stream, supporting MU-MIMO
- 20 MHz Wi-Fi channels
- Wi-Fi 802.11a/b/g/n/ac/ax/ - d/e/h/i/r/w
- Bluetooth 5.4 supporting LE Audio
- Wi-Fi security: WPA3, WPA2, WAPI, AES
- High-power Bluetooth: up to +20 dBm
- Secure boot
- Industrial temperature range -40°C to +85°C
Product Image
