AD9914BCPZ Integrated Circuit Chip 3.5GSPS Direct Digital Synthesizer with 12-bit DAC and 190 pHz Frequency Tuning Resolution

Large Image : AD9914BCPZ Integrated Circuit Chip 3.5GSPS Direct Digital Synthesizer with 12-bit DAC and 190 pHz Frequency Tuning Resolution

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	AD9914BCPZ

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	LFCSP-88
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

AD9914BCPZ Integrated Circuit Chip 3.5GSPS Direct Digital Synthesizer with 12-bit DAC and 190 pHz Frequency Tuning Resolution

Description

Part Number:	AD9914BCPZ	Product Type:	Direct Digital Syntheses
Internal Clock Speed:	3.5 GSPS	Frequency Tuning Resolution:	Up To 190 PHz
Phase Noise:	−128 DBc/Hz (1 KHz Offset At 1396 MHz)	Wideband SFDR:	<-50 DBc
Highlight:	3.5 GSPS Direct Digital Synthesizer , 12-bit DAC Integrated Circuit Chip , 190 pHz Frequency Tuning Resolution DDS

AD9914BCPZ Integrated Circuit Chip 3.5GSPS Direct Digital Synthesizer LFCSP-88

The AD9914BCPZ is a high-performance direct digital synthesizer (DDS) featuring a 12-bit DAC. This advanced IC utilizes cutting-edge DDS technology combined with an internal high-speed, high-performance DAC to create a digitally programmable, complete high-frequency synthesizer capable of generating frequency-agile analog output sinusoidal waveforms at up to 1.4 GHz.

This synthesizer enables rapid frequency hopping and provides exceptional tuning resolution (64-bit capable using programmable modulus mode). The AD9914 also offers fast phase and amplitude hopping capabilities. Frequency tuning and control words are loaded into the device via serial or parallel input/output ports.

Technical Specifications

Parameter	Value
Mounting Style	SMD/SMT
Package / Case	LFCSP-88
Product Type	Direct Digital Synthesizer
Resolution	12 bit
Number of Channels	1 Channel
Supply Voltage Range	1.8 V to 3.3 V
Operating Temperature	-40℃ to +85℃
Interface Type	Serial
Number of Converters	1 Converter
Number of DAC Channels	1 DAC Channel

Key Features

3.5 GSPS internal clock speed
Integrated 12-bit DAC
Frequency tuning resolution to 190 pHz
16-bit phase tuning resolution
12-bit amplitude scaling
Programmable modulus
Automatic linear and nonlinear frequency sweeping capability
32-bit parallel datapath interface
8 frequency/phase offset profiles
Phase noise: −128 dBc/Hz (1 kHz offset at 1396 MHz)
Wideband SFDR < -50 dBc
Serial or parallel input/output control
1.8 V/3.3 V power supplies
Software and hardware controlled power-down
88-lead LFCSP package
PLL REF CLK multiplier
Phase modulation capability
Amplitude modulation capability

Applications

Agile LO frequency synthesis
Programmable clock generator
FM chirp source for radar and scanning systems
Test and measurement equipment
Acousto-optic device drivers
Polar modulator
Fast frequency hopping systems
