IPD90N04S4-03 Integrated Circuit Chip 40V 90A OptiMOS™-T2 Automotive MOSFET Transistors
IPD90N04S4-03 Integrated Circuit Chip 40V 90A OptiMOS™-T2 Automotive MOSFET Transistors
Product Description
IPD90N04S4-03 is an N-channel enhancement mode automotive-grade power MOSFET from the OptiMOS™-T2 series, housed in a TO-252-3 (DPAK) package. Featuring a 40V breakdown voltage, 90A continuous current rating, and low on-resistance of 3.2mΩ. Certified to AEC-Q101 standards, it is suitable for automotive electronics and industrial high-current switching applications.
Specifications
| Series |
OptiMOS™ |
| FET Type |
N-Channel |
| Technology |
MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) |
40 V |
| Current - Continuous Drain (Id) @ 25°C |
90A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) |
10V |
| Rds On (Max) @ Id, Vgs |
3.2mOhm @ 90A, 10V |
| Vgs(th) (Max) @ Id |
4V @ 53µA |
| Gate Charge (Qg) (Max) @ Vgs |
66.8 nC @ 10 V |
| Vgs (Max) |
±20V |
| Input Capacitance (Ciss) (Max) @ Vds |
5260 pF @ 25 V |
| Power Dissipation (Max) |
94W (Tc) |
| Operating Temperature |
-55°C ~ 175°C (TJ) |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
PG-TO252-3-313 |
| Package / Case |
TO-252-3, DPAK (2 Leads + Tab), SC-63 |
Key Features
- N-channel - Enhancement mode
- Automotive AEC Q101 qualified
- MSL1 up to 260°C peak reflow
- 175°C operating temperature
- Green product (RoHS compliant)
- 100% Avalanche tested
- PPAP Capable Device
Applications
Automotive: Chassis control and safety systems
