LTC3610EWP Integrated Circuit Chip 12A Output Current 4V to 24V Input Range Monolithic Synchronous Step-Down DC/DC Converter

LTC3610EWP Integrated Circuit Chip 12A Output Current 4V to 24V Input Range Monolithic Synchronous Step-Down DC/DC Converter
LTC3610EWP Integrated Circuit Chip 12A Output Current 4V to 24V Input Range Monolithic Synchronous Step-Down DC/DC Converter

Large Image :  LTC3610EWP Integrated Circuit Chip 12A Output Current 4V to 24V Input Range Monolithic Synchronous Step-Down DC/DC Converter

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LTC3610EWP
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 64-QFN
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

LTC3610EWP Integrated Circuit Chip 12A Output Current 4V to 24V Input Range Monolithic Synchronous Step-Down DC/DC Converter

Description
Part Number: LTC3610EWP Function: Step-Down
Output Configuration: Positive Topology: Buck
Output Type: Output Type Number Of Outputs: 1
Highlight:

12A Output Current Integrated Circuit Chip

,

4V to 24V Input Range DC/DC Converter

,

Monolithic Synchronous LTC3610EWP

LTC3610EWP Integrated Circuit Chip 24V 12A Monolithic Synchronous Step-Down DC/DC Converter
The LTC3610EWP is a high-efficiency, monolithic synchronous step-down DC/DC converter capable of delivering up to 12A output current from a 4V to 24V input supply (28V maximum). Utilizing valley current control architecture, it enables very low duty cycle operation at high frequency with excellent transient response. The operating frequency is selectable via an external resistor and compensates for variations in VIN and VOUT.
The LTC3610EWP can be configured for either discontinuous or forced continuous operation at light load. Forced continuous operation reduces noise and RF interference, while discontinuous mode provides high efficiency by minimizing switching losses at light loads.
Specifications
Voltage - Input (Min) 4V
Voltage - Input (Max) 24V
Voltage - Output (Min/Fixed) 0.6V
Voltage - Output (Max) 24V
Current - Output 12A
Synchronous Rectifier No
Operating Temperature -40°C ~ 125°C (TJ)
Key Features
12A Output Current
Wide VIN Range = 4V to 24V
Internal N-Channel MOSFETs
True Current Mode Control
Optimized for High Step-Down Ratios
tON(MIN) ≤100ns
Extremely Fast Transient Response
Stable with Ceramic COUT
±1% 0.6V Voltage Reference
Power Good Output Voltage Monitor
Adjustable On-Time/Switching Frequency
Adjustable Current Limit
Programmable Soft-Start
Output Overvoltage Protection
Optional Short-Circuit Shutdown Timer
Low Shutdown IQ: 15μA
Available in 9mm * 9mm 64-Pin QFN Package
Applications
  • Point of Load Regulation
  • Distributed Power Systems
